Quick Details
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ACCTEK
-
Weight (KG):
-
300 KG
-
Marking Speed:
-
≤8000mm/S
-
Max.Marking Depth:
-
≤1mm
-
Controller:
-
Customized system
-
Working table type:
-
Aluminum alloy& PVC table
-
Power:
-
20w/30w/50W/100w
-
Laser Wavelength:
-
1064nm
Quick Details
-
Working Accuracy:
-
±0.001mm
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, PLT, DXP
-
Laser Type:
-
Fiber Laser
-
Cooling Mode:
-
Air Cooling
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ACCTEK
-
Weight (KG):
-
300 KG
-
Marking Speed:
-
≤8000mm/S
-
Max.Marking Depth:
-
≤1mm
-
Controller:
-
Customized system
-
Working table type:
-
Aluminum alloy& PVC table
-
Power:
-
20w/30w/50W/100w
-
Laser Wavelength:
-
1064nm
Co2 laser marking machine 1325 big size for wood logo and stone etc
Advantages of RF tube Co2 laser marking machine
1. High cut/engrave speed
This series machine adopts advanced Galvo scanning system. The cutting/engraving speed can reach 7000mm/s. Fulfill the request of factory mass production.
2. Precise process
With US RF metal laser tube or Reci laser tube, this machine has finest laser beam, to cut and engrave very precisely. Especially when you cut paper card, the cutting edge is very smooth and thin.
3. Forever lasting marking
Laser is non contact process, there is no distortion. As laser marking is to gasify the surface of material, the marking will laser forever.
4. Flexible process
You just need to change design in software, then all different size/shape pattern can be realized. It is very convenient for sampling or changing products. No need cost for template.
5. Easy operation
Adopting integrated structure with Auto focusing technology and humanized operation design. Making the laser marking as easy as printing.
6. Minimal owner ship cost
No need any maintenance, long life, small volume, suits for working in atrocious working conditions.
7 Wide application
This machine can mark, engrave, cut, hollow on almost all non-metal material, like wood, acrylic, plastic, marble, paper, glass, leather, textile, bamboo, PVC, rubber and so on.
It is widely applied in industry like electronic, machinery, garments, artwork, gifts, greeting card, packing, advertisement ect.
It can process with any pattern, signs, bar code, letters, serial number as request.
Parameter of Co2 laser marking machine
| Model | AK1325C |
| Working size | 1300X2500mm |
| Laser Power | USA Synrad 10w/30W/60W metal laser Co2 tube |
| Galvo system | High quality Galvo scanning system |
| Laser Power Control | 0-100% Software Controlling |
| Axial Speed | 0-8000mm/s |
| Motion System | Servo Motor/ stepper motor |
| Repeat Location Accuracy | ± 0.01mm |
| Voltage | 110V/220V 50HZ/60HZ |
| Cooling System | Industrial water chiller |
| Min character | 0.3mm |
| User Control | Digital Screen Panel |
| Operate system | Windows XP/7/8/10 |
| Format Support | PLT/DXF/AI/SDT/BMP/JPG/JPEG/GIF/TGA/PNG/TIF/TIFF |
| CorelDraw/PhotoShop/AutoCAD/Illustrator | |
| Software | Customized system |
| Cooling | Air cooling |
| Machine package dimension | Length*width*height :2100x3500x1650mm |
| Gross weight:950kgs |
Detail imagines:
Applications of Co2 laser marking machine
After-sale service:
1. 18 months guarantee of the whole machine.
2. Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
3. Lifetime maintenance free of charge.
4. We will provide the consumable parts at a factory price when you need replacement.
5. Machine has been adjusted before delivery.
6. Our staff can be sent to your company to install or adjust if necessary.
A:T/T:30% T/T deposite,70% before shippment.
This is the most convinent payment terms for international trade.
B: Pay-pal
C: Western Union: only small order.
