Quick Details
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Solar
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Voltage (V):
-
220
-
Recommended Room Size（square feet）:
-
100
-
Product Name:
-
Solar Powered Air Conditioner
-
Function:
-
Cooling\Heating
-
Keyword:
-
Solar Hybrid Air Conditioner
-
Refrigerant:
-
R-410A
-
Cooling capacity:
-
9000btu 12000btu 18000btu 20000btu 24000btu
Quick Details
-
Capacity (btu):
-
＞12001
-
EER:
-
＜2
-
Type:
-
Split Wall Mounted Air Conditioners
-
Cooling/Heating:
-
Cooling/Heating
-
Power Source:
-
Solar
-
App-Controlled:
-
Yes
-
Fixed Frequency/Variable Frequency:
-
Fixed frequency
-
Voltage (V):
-
220
-
Recommended Room Size（square feet）:
-
100
-
Product Name:
-
Solar Powered Air Conditioner
-
Function:
-
Cooling\Heating
-
Keyword:
-
Solar Hybrid Air Conditioner
-
Refrigerant:
-
R-410A
-
Cooling capacity:
-
9000btu 12000btu 18000btu 20000btu 24000btu
Specification
|
DC AIR CONDITIONER
|
|
|
|
|
||||
|
Power Supply：
|
48VDC (44V to 58 V)
|
|
|
|
||||
|
Model No
|
TKFR-26GW/DC
|
TKFR-35GW/DC
|
TKFR-52GW/DC
|
TKF-72GW/DC
|
||||
|
Max Solar Charging Current
|
MAX15A
|
|
|
|
||||
|
AC Power Connected
|
180-240V (50/60HZ)
|
|
|
|
||||
|
Cooling:
|
|
|
|
|
||||
|
Capacity
|
9000 Btu/h
|
12000 Btu/h
|
18000 Btu/h
|
24000Btu/h
|
||||
|
Dimension(mm)
indoor unit
|
775*270*195 |
775*270*195
|
985×300×220
|
985×300×220
|
||||
|
Power Input
|
0.81Kw
|
0.98Kw
|
1.51Kw
|
1.87Kw
|
||||
|
EER
|
15.79 Btu/h/W
|
17.14Btu/h/W
|
20.00Btu/h/W
|
16.00Btu/h/W
|
||||
|
Heating:
|
|
|
|
|
||||
|
Capacity
|
9000 Btu/h
|
12000 Btu/h
|
18000 Btu/h
|
24000 Btu/h
|
||||
|
Dimension(mm)
Outdoor Unit
|
790*260*540
|
790*260*540
|
850* 290* 580
|
865*310*710
|
||||
|
Power Input
|
500w
|
700w
|
900w
|
1300w
|
||||
|
HSPF/COP
|
12/13.4 Btu/W
|
11/12.38 Btu/W
|
10/12.41 Btu/W
|
11/12.31 Btu/W
|
||||
|
Weight(kg)
|
|
|
|
|
||||
|
Indoor Unit
|
11
|
13
|
15
|
20
|
||||
|
Outdoor Unit
|
38
|
45
|
48
|
48
|
||||
product description
Solar air conditioner is engineered from the ground up for use with solar. All electrical components are DC powered including compressor, high-efficiency DC fan motors, DC valves & solenoids, etc. The Solar system uses a VRF (Variable Refrigerant Flow) controller and frequency driver in conjunction with multiple sensors and an algorithmic control circuit to raise and lower the unit's capacity in real-time based on conditions as they change. Hybrid Inverter Solar air conditioner are more powerful and use less energy than a fixed speed air conditioner.
Using Recreate* s Solar direct drive technology (SDDA) the Recreate Solar Hybrid unit can use Solar DC gener ated power or mains AC generated power, or a combina tion of both as required. This means that the Recreate Hybrid requires NO batteries, NO inverter, NO controller and need only a few PV panels to deliver a huge savings.Under optimum conditions, this can save up to 97% of your mains power usage.
Benefits of Recreate ACDC Hybrid
Connects Directly to the Solar Panel Runs on up to 100% solar power directly in daytime that would save you up to 97% of you power bill Easy Solar Connections Connection from the solar panels to the Recreate Solar Hybrid outdoor is very simple with a terminal block mounted in the outdoor unit for the positive and negative cables straight from the solar panels. Super applicability Wide operating temperature range: -10 °C to +52 °C, Meet T3 work environment Wide operating AC voltage range: AC 160V-250V,meet the remote network voltage instability area
