Quick Details
-
Controller Type:
-
MPPT
-
Special Features:
-
Wireless Charging, Remote Control, Type C, Flashlight, jump starter, RV Port, Cigar Lighter, Air Compressor, External Battery
-
Model Number:
-
TKEM-M2
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TAICO
-
System Voltage:
-
Other
-
Sealed Type:
-
Sealed
-
Maintenance Type:
-
Free
-
Voltage:
-
24v/25.6v
-
OEM:
-
Available
-
Sample:
-
Available
-
Usage:
-
balance the voltage
-
Capacity:
-
100ah
-
Nominal Voltage:
-
25.6Volts
-
Keywords:
-
Battery Lithium Lifepo4
Quick Details
-
Power Source:
-
Car, Solar Panel
-
Battery Type:
-
Lithium Ion
-
Inverter Type:
-
Pure Sine Wave
-
Controller Type:
-
MPPT
-
Special Features:
-
Wireless Charging, Remote Control, Type C, Flashlight, jump starter, RV Port, Cigar Lighter, Air Compressor, External Battery
-
Model Number:
-
TKEM-M2
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TAICO
-
System Voltage:
-
Other
-
Sealed Type:
-
Sealed
-
Maintenance Type:
-
Free
-
Voltage:
-
24v/25.6v
-
OEM:
-
Available
-
Sample:
-
Available
-
Usage:
-
balance the voltage
-
Capacity:
-
100ah
-
Nominal Voltage:
-
25.6Volts
-
Keywords:
-
Battery Lithium Lifepo4
Product Description
Specification
|
SPECIFICATION
|
TKEM-M1 1KW/1280WH
|
TKEM-M2 1KW/2560WH
|
TKEM-M3 2KW/2560WH
|
||
|
INVERTER/CHARGER
|
|
|
|
||
|
Inverter Type
|
1KW/25.6V
|
1.2KW/25.6V
|
2KW/51.2V
|
||
|
Rated Output Power
|
2KW
|
2.4KW
|
4KW
|
||
|
Output Voltage Waveform
|
Pure Sine Wave
|
|
230VAC
|
||
|
Output Voltage
|
230VAC
|
|
|
||
|
Low DC Warning Voltage
|
22.4Vdc
|
|
44.8Vdc
|
||
|
Low DC Cut-off Voltage
|
21.6Vdc
|
|
43.2Vdc
|
||
|
Low DC Warning Return Voltage
|
22.4Vdc
|
|
44.8Vdc
|
||
|
Total Charging Current(Grid+solar)
|
20A Max.
|
|
20A Max.
|
||
|
Bulk Charging Voltage
|
29.3Vdc
|
|
58.6Vdc
|
||
|
Float Charging Voltage
|
28.8Vdc
|
|
57.6Vdc
|
||
|
LITHIUM IRON BATTERY
|
|
|
|
||
|
Normal Battery Modular
|
25.6V50Ah
|
25.6v 100ah
|
51.2v 50ah
|
||
|
Normal Capacity (25°C,0.2C)
|
1280Wh
|
2560 Wh
|
|
||
|
Nominal Battery Voltage
|
25.6Vdc
|
|
51.2Vdc
|
||
|
Max.Charge Current
|
60A
|
|
|
||
|
Max.Discharge Current
|
60A
|
|
|
||
|
Operation Voltage Range
|
22.4Vdc~29.2Vdc
|
|
40V-58.4V
|
||
|
Operation Temperature
|
-23°C~+65°C
|
|
|
||
|
AC INPUT
|
|
|
|
||
|
Nominal Input Voltage
|
230Vac
|
|
|
||
|
Low Loss Voltage
|
170Vac +7(UPS),90Vac+ 7(Appliances
|
|
|
||
|
Low Loss Returm Voltage
|
180Vac土7(UPS),100Vac7(Appliances
|
|
|
||
|
High Loss Voltage
|
250Vac土7
|
|
|
||
|
High Loss Returm Voltage
|
260Vac土7
|
|
|
||
|
Max. AC Input Voltage
|
265V ac
|
|
|
||
|
Nominal Input Frequency
|
50HZ
|
|
|
||
|
AC Charging Current
|
20AMax
|
|
|
||
|
SOLAR INPUT
|
|
|
|
||
|
Nominal PV Voltage
|
36Vdc
|
|
|
||
|
PV Array MPPT Voltage Range
|
30Vdc~60Vdc
|
|
|
||
|
Max. PV Array Open Circuit Voltage
|
60Vdc
|
|
|
||
|
Solar Charging Current
|
10A Max.
|
|
|
||
|
PRODUCTS SIZE(mm)
|
432*190*395
|
432*190*395
|
updating
|
||
|
Cartoon size (mm)
|
500*260*465
|
500*260*465
|
updating
|
||
|
PROTECTION
|
|
|
|
||
|
Protection
|
Overcharge protection 、Overdischarge protection 、Overcurrent 、protection.
|
|
|
||
|
AMBIENT
|
|
|
|
||
|
Noise(dB)
|
<30°C < 40dB (1 meter)
|
|
|
||
|
Working Temperature
|
-23°C~+65°C
|
|
|
||
|
Humidity
|
0~95%( no condensation)
|
|
|
||
|
Sea Level(m)
|
<1500
|
|
|
||
|
OTHERS
|
|
|
|
||
|
Effeciency
|
92.0%
|
|
|
||
