tk2207 tk2317 tk3317 VHF Dual Band Long Range FM Keypad DTMF QT DQT Signalling Portable woki toki two way Radio walkie talkie

tk2207 tk2317 tk3317 VHF Dual Band Long Range FM Keypad DTMF QT DQT Signalling Portable woki toki two way Radio walkie talkie

FOB Reference Price: Get Latest Price

≥1 Pieces

US $31.46

≥100 Pieces

US $27.83

≥1000 Pieces

US $26.25

≥100000 Pieces

US $21.15

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Walkie Talkie Type:: Handheld walkie talkie

Place of Origin:: China

Brand Name:: TK

Model Number:: tk2207 tk2317 tk3317

Dimensions:: 113 x 54 x 14 mm

Frequency Range:: VHF: 136-174mhz; UHF 400-470MHz

Output Power:: 5w

Channel Spacing:: 25 kHz / 12.5 kHz

Operating Voltage:: 7.5 V DC +- 20%

Battery Life:: 10hrs

Frequency Stability:: 2.5ppm

Antenna Impedance:: 50 Ohm

Operating Temperature:: -20 deg C to +60 deg C

Weight:: 130g(with battery & antenna)

Audio Distortion:: Less than 5%

Product Name:: TK2000/TK3000 radio single band vhf uhf walkie talkie

Quick Details

Talk Range:: about 3-6 km

Terminal style:: Handheld

Storage Channel:: 16 Channels

Walkie Talkie Type:: Handheld walkie talkie

Place of Origin:: China

Brand Name:: TK

Model Number:: tk2207 tk2317 tk3317

Dimensions:: 113 x 54 x 14 mm

Frequency Range:: VHF: 136-174mhz; UHF 400-470MHz

Output Power:: 5w

Channel Spacing:: 25 kHz / 12.5 kHz

Operating Voltage:: 7.5 V DC +- 20%

Battery Life:: 10hrs

Frequency Stability:: 2.5ppm

Antenna Impedance:: 50 Ohm

Operating Temperature:: -20 deg C to +60 deg C

Weight:: 130g(with battery & antenna)

Audio Distortion:: Less than 5%

Product Name:: TK2000/TK3000 radio single band vhf uhf walkie talkie

Please communicate before placing an order

If the MOQ is less than 500, we will ship ordinary models

Starting from MOQ500, support customization

The new TK-2317/3317 is thin and compact yet packed with features for intuitive operation, impressive performance, and all-weather reliability. Front and side programmable function keys allow for customized convenience, and KENWOOD’s renowned audio clarity means the message gets through loud and clear. Offering extensive frequency coverage – 70MHz for UHF – the TK-2317/3317 is ideal for a wide range of applications. The 128-channel, 128-zone capacity is ample for any current or future requirement in any radio system. Output is 5W for both VHF and UHF. GPS CONNECTIVITY Combined with the optional KMC-48GPS Speaker Mic, the TK-2317/3317 can function as a mobile station for KENWOOD’s AVL system. All front and side keys can be assigned individual functions, allowing this radio to be customized for easy one-touch operation suited to specific requirements. It is also possible to directly input a channel number using a key assigned with that number (12-key keypad models only). The 8-character, 13-segment backlit LCD with icons and RSSI display makes channel information and FleetSync® messaging easy to read, day or night. In addition to the red/orange/green LED indicators, a blue LED has been added for quick visual confirmation. The built-in programmable voice inversion scrambler provides protection against casual eavesdropping.

*This function cannot be used in certain countries. Please contact your KENWOOD dealer or further information. SIGNALING - QT / DQT / DTMF - FleetSync® PTT ID, SelCall - 2-tone (encode/decode) - Built-in MDC-1200 signaling FleetSync® and MDC-1200 signaling can be independently selected for each zone. Switching between them is as simple as changing zones. For hazardous/hostile environments, side PF keys can be programmed for Emergency use to transmit an alert to a predetermined person or group using DTMF, FleetSync® or MDC-1200 signaling. The tough TK-2317/3317 has passed the demanding IP54/55 tests, even with the optional speaker microphone KMC-45 attached (locking bracket required). It also meets or exceeds 11 MIL-STD 810 C/D/E/F/G environmental standards, including “blowing rain”. As an experienced audio specialist, KENWOOD has decades of expertise that is reflected in every KENWOOD radio – from component selection and construction to optimization, evaluation and analysis. The resulting audio performance, specially engineered for transceivers, is undeniably clearer and crisper. Just listen to the difference.

Features:

* Thin & Lightweight
* 16 Channels with Scan Function
* Programmable Function Key with Hold
* All-in-one Package
* Robust & Reliable
* Output Power 5W (VHF) / 4W (UHF)
* QT / DQT
* DTMF Enc.
* Priority Scan
* Windows® Programming and Tuning
* Wide/Narrow Channel Bandwidth
* VOX ready
* Battery-Saver
* Busy Channel Lockout
* Time-Out-Timer
* Low-Battery Alert
* Tri-Colour LED
* Wired

Does your company require employees to work overtime?

Our company does not allow employees to work overtime, strictly in accordance with the management system!

1. Are you a trading company or a manufacturer?
We are a factory, we have been engaged in the walkie-talkie industry for more than 20 years, with a factory of 3000 square meters.

2. Can I get samples before bulk ordering?
Yes, we are always happy to send you samples of our products. Just let us know your request and shipping address.

3. Do you accept ODM/OEM orders?
Yes, we can accept OEM/ODM, MOQ: 500pcs You can change the logo and function as you want.

4. What is your quality control process?
We 100% test all products before packaging. We have an excellent QC process and department who check every product and make sure the radio/car radio is working properly before shipping.

5. What is the payment method?
For bulk orders, we recommend T/T, for small orders, we recommend Alibaba Trade Assurance, Western Union.

6. What is the best price for this walkie-talkie/car radio?
We will quote you the best price based on your quantity, so when you inquire, please tell us the quantity you want.

7. What is your MOQ?
No MOQ, we can also accept sample orders, but we recommend buying more than 100 pcs to save shipping.

8. What is your packaging?
Our product packaging is a color box, which can be ordered in bulk with customized packaging boxes. If you want a new package,then you can send me your new design and tell us your requirements.
