Quick Details
-
Power:
-
Customized
-
Dimension(L*W*H):
-
customized
-
Weight:
-
68 KG
-
Name:
-
evaporator(air cooler)
-
Reached Temperature:
-
+15℃~-80℃
-
Cooling Type:
-
Air Cooler
-
Product Type:
-
DD,DL,DJ
-
Size:
-
Different sizes
-
Fin material:
-
Aluminum Corrosion Resistant
-
Fan Motor:
-
Axial Motor
-
cooling capacity:
-
2.1-152KW
-
Feature:
-
Energy saving and High efficiency
-
Usage:
-
cold room,cool room,walk in cooler,walk in freezer
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HANYANG
-
Voltage:
-
380V,220V,440V,230V etc.
-
Power:
-
Customized
-
Dimension(L*W*H):
-
customized
-
Weight:
-
68 KG
-
Name:
-
evaporator(air cooler)
-
Reached Temperature:
-
+15℃~-80℃
-
Cooling Type:
-
Air Cooler
-
Product Type:
-
DD,DL,DJ
-
Size:
-
Different sizes
-
Fin material:
-
Aluminum Corrosion Resistant
-
Fan Motor:
-
Axial Motor
-
cooling capacity:
-
2.1-152KW
-
Feature:
-
Energy saving and High efficiency
-
Usage:
-
cold room,cool room,walk in cooler,walk in freezer
Product Description
| Evaporator Introduction |
| Cold room evaporator can be used as cooling device in different kinds of cold storages, like chiller room, frozen room and blast freezer room. There are DL, DD and DJ model cold room evaporator, which are suit for different room usages. |
| Cold room evaporator features |
| 1.Cold room evaporator has reasonable structure, uniform frosting and high efficiency heat exchange. |
| 2.The shell is made of high-quality steel with surface plastic-sprayed, which is corrosion-resistant. Stainless steel shell is optional. |
| 3.Cold room evaporator are assembled with high-quality fan motor with low noise, big air volume. Air duct can be customized for long-distance air. |
| 4.Cold room evaporator is equipped with U-shaped stainless copper pipe evenly, which can shorten the defrosting time. |
| 5.Water defrosting and electric defrosting are optional. |
| How to select evaporator |
| 1.When the cold room temperature is around 0°C, select 4.5mm(DL model) as fin space. |
| 2.When the cold room temperature is around -18°C, select 6mm(DD model) as fin space. |
| 3.When the cold room temperature is around -25°C, select 9mm(DJ model) as fin space. |
| Advantage |
| 1,The shell is made of quality steel plate; plastic-sprayed surface is anti-corrosive and its appearance is beautiful. |
| 2,Run without high power electric equipment inside the cold storage high security. |
| 3,Water defrosting realizes quick defrosting which can achieve good effect and less energy consumption The rolls temperature rise of small. |
| 4, Long-distance air supply or explosion-proof motors can be used according to customers requirements. |
| 5, Can be customized according to customer requirements. |
