Quick Details
-
Operating Temperature::
-
-40°c~80°c
-
Transmitting Power::
-
≤5W
-
Frequency stability::
-
≤±2.5PPm
-
Serial Data Rate::
-
1200~115200bps
-
Receiving current::
-
≤80mA
-
Modulation ::
-
GFSK
-
Power Supply::
-
12v@3A
-
Interface::
-
RS232&RS485
-
Interface Data Format::
-
8N1/8E1/8O1
-
sensitivity::
-
-125dBm@1200bps/-120dBm@9600bps
Quick Details
-
Model Number:
-
XZ-DT25-M
-
Type:
-
Radio frequency module
-
Place of Origin:
-
Guangdong, China
-
Operating Temperature::
-
-40°c~80°c
-
Transmitting Power::
-
≤5W
-
Frequency stability::
-
≤±2.5PPm
-
Serial Data Rate::
-
1200~115200bps
-
Receiving current::
-
≤80mA
-
Modulation ::
-
GFSK
-
Power Supply::
-
12v@3A
-
Interface::
-
RS232&RS485
-
Interface Data Format::
-
8N1/8E1/8O1
-
sensitivity::
-
-125dBm@1200bps/-120dBm@9600bps
Product Description
Product Paramenters
|
Function
|
The transmission power is up to 5W and the maximum sensitivity is - 123dbm. Transparent data transmission and intelligent data
control |
|
Feature
|
1. Support RS232&RS485 interface,TTL customized; 2. 8km-12km LOS long range transmission distance;
3.1200bps- 115200bps user programming; 4.short transmitting-receiving transfer time; communication delay less than 3MS. |
|
Usage
|
Oil and gas production, pipeline monitoring, gas distribution, heat network monitoring. Water source well, tap water and
wastewater treatment monitoring system. Power dispatching, distribution automation, load control. GPS positioning system, mobile data transmission. Earthquake, meteorology, environmental protection and urban lighting control. Railway, transportation, metallurgy, chemical industry and industrial automation process control. Ship (umv) measurement and control, robot control data link. Military and police communications. Industrial remote control, telemetry and automatic data acquisition system. |
