- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
DEFU PUMP
-
Model Number:
-
650HW-10S
-
Place of Origin:
-
Zhejiang, China
-
Outlet Size:
-
26"
-
Power:
-
243kw
-
motor:
-
/
-
Usage:
-
Water
-
Fuel:
-
Diesel
-
Theory:
-
Mixed Flow Pump
-
Pump Material:
-
Cast Iron
-
Impeller Material:
-
Cast Iron
-
Pump Type:
-
Horizontal Pump
Quick Details
-
Application:
-
Irrigation and Agriculture, Water
-
Pressure:
-
Low Pressure
-
Voltage:
-
/
-
Warranty:
-
1 year
-
Brand Name:
-
DEFU PUMP
-
Model Number:
-
650HW-10S
-
Place of Origin:
-
Zhejiang, China
-
Outlet Size:
-
26"
-
Power:
-
243kw
-
motor:
-
/
-
Usage:
-
Water
-
Fuel:
-
Diesel
-
Theory:
-
Mixed Flow Pump
-
Pump Material:
-
Cast Iron
-
Impeller Material:
-
Cast Iron
-
Pump Type:
-
Horizontal Pump
Product Description
The mixed-flow pump is one of the horizontal, single stage, single suction volute mixed flow pump.The head is low and the capacity is large.The pump has many features such as small body, light weight, simple structure, simple operation, convenient maintenance and repair, high efficiency.
|
Type
|
HW series mixed flow pump
|
|
Structure
|
Horizontal, single stage, single suction
|
|
Size
|
4inch, 6 inch,8 inch,10 inch,12 inch,14 inch,16 inch, 20 inch, 26 inch, 32 inch
|
|
Max. Flow
|
8640 m³/h
|
|
Max. Head
|
21.5 m
|
|
Rotation Speed
|
450-2900rpm
|
|
Shaft Powe
|
3-400kw
|
|
Seal
|
Glad Packing Seal or Mechanical Sea
|
|
Pump Materia
|
Cast Iron
|
|
mpeller Materia
|
Cast Iron, Stainless Stee
|
Appilication
Suitable for transporting pure water or the other liquid with both physical and chemical natures similar to those of water, with the temperature of the liquid to be transported not over 50 ℃, for the farm land irrigation, industrial and city water supply and drainage etc. multiple places.
