Atex explosion proof Handheld Ammonia NH3 Gas Detector meter monitor with data logger

Atex explosion proof Handheld Ammonia NH3 Gas Detector meter monitor with data logger

FOB Reference Price: Get Latest Price

≥1 Pieces

US $170

≥20 Pieces

US $150

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: HuaFan

Model Number:: HFP-1201

Product name:: Portable NH3 Concentration Monitor Ammonia Gas Detector

Detecting Gas:: NH3

Sensor:: Electrochemical Sensor

Measure Range:: 0-200ppm

Power supply:: Rechargeable Lithium Battery

Alarm Type:: Vibration+Sound+Light Alarm

Display:: LCD Display

Response time:: 30s

certification:: ATEX CE

Resolution:: 1ppm

Quick Details

Type:: Portable Type

Warranty:: 1 year

Place of Origin:: Shaanxi, China

Brand Name:: HuaFan

Model Number:: HFP-1201

Product name:: Portable NH3 Concentration Monitor Ammonia Gas Detector

Detecting Gas:: NH3

Sensor:: Electrochemical Sensor

Measure Range:: 0-200ppm

Power supply:: Rechargeable Lithium Battery

Alarm Type:: Vibration+Sound+Light Alarm

Display:: LCD Display

Response time:: 30s

certification:: ATEX CE

Resolution:: 1ppm

Products Description

Atex explosion proof Handheld Ammonia NH3 Gas Detector meter monitor with data logger

This portable NH3 gas detector uses electrochemical sensor from UK,test gas concentration by natural diffusion model,default measure range is 0-200ppm,when the gas concentration exceed the alarm point ,the detector will send three types alarm to remind and avoid the accident.

Brief Introduction:

* High precision sensor from UK

* LCD display in English
* Sound,light and vibration alarms
* Two alarm points,adjustable
* Calendar real time in English
* Back alligator clip design
* Save 3000 alarm records
* Low voltage reminder
* USB charger,1800mAh Li battery
* Computer connection is optional
* CE and ATEX certificates
* One year warranty

Advantages

1. High sensitive sensor from UK;

2. LCD display with calendar real timely;
3. Three alarms: Audible, visual and vibration;
4. Low and high alarm points,can be set by user;
5. Detect gas concentration by natural diffusion mode;
6. 1800mAh lithium battery,rechargeable;
7. Back alligator clip design,easy to carry and use;
8. Can keep 3000 alarm records,view by button or computer;
9. Displaying battery capacity, low battery indication and automatic turn-off;
10. CE ATEX Explosion proof, water proof and dust proof.

Data logger and transfer function : ( Optional )

Connection with computer to save, transfer and printing data function is optional,detailed instruction refer to single portable configuration software manual.

Product Parameters

Name	Atex explosion proof Handheld Ammonia NH3 Gas Detector meter monitor with data logger
Size and weight	108mm61mm40mm, 135g
Sensor type	Electrochemistry method
Sampling type:	Natural Diffusion
Destination gas	NH3
Measure range	0-200ppm,support customization
Resolution	1ppm
Response time	≤20s
Display	LCD large screen display in English
Alarm	Voice alarm more than 90dB + light alarm Red LED + Vibration
Power supply	the lithium battery power supply (1800 mAh) rechargeable
Charge time	3-5hours
Charging voltage	DC5V
Storage	Save 3000 alarm records and real time value
Optional	Software with USB (connect with computer for data analysis and printing)
Features	With zero setting, alarm point set, can be calibrated,restore factory settings
Certificates	CE/ATEX/ISO9001/CNEX
Temperature range	- 20 ℃ ~ 50 ℃
Humidity	15% ~ 95% RH (No condensation)
