Quick Details
-
Color:
-
Grey
-
Floor:
-
5-layer insulated floor
-
Roof:
-
3-layers Sandwich Panel+ Decoration Ceiling
-
Structure:
-
3mm prefabricated Steel Frame Structure + Sandwich Panel
-
Window:
-
double-layered Aluminum Window
-
Certification:
-
ISO9001
-
Electricity:
-
Sockets
-
Installation:
-
Flexible Assemble
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Tseason
-
Type:
-
Prefabricated Modular Houses
-
Color:
-
Grey
-
Floor:
-
5-layer insulated floor
-
Roof:
-
3-layers Sandwich Panel+ Decoration Ceiling
-
Structure:
-
3mm prefabricated Steel Frame Structure + Sandwich Panel
-
Window:
-
double-layered Aluminum Window
-
Certification:
-
ISO9001
-
Electricity:
-
Sockets
-
Installation:
-
Flexible Assemble
Product Paramenters
|
Item
|
specification
|
|
standard size
|
6020*2345*2820mm
|
|
weight
|
2000kg
|
|
top and bottom frame
|
thickness 3mm , Cold formed galvanized integrated steel structure
|
|
column
|
thickness 3mm , Cold formed galvanized integrated steel structure
|
|
roof
|
Outside:0.5mm thickness anti-corrosion A-Zn steel plate with PE coating
Insulation:polyurethane foaming
Ceiling:Polyurethane/rock wool sandwich panel, thickness 30mm
|
|
floor
|
External:0.5mm thickness anti-corrosion A-Zn steel plate
Insulation: XPS board+15mm calcium silicate board
Inside decoration:1.6mm rubber plastic floor ( can be customized)
Permitted loading: 2.0 KN/㎡
|
|
wall
|
Polyurethane/rock wool sandwich panel, thickness 50mm-200mm
Thickness of panel’s both surface is 0.4mm thickness AL-ZN steel plate,
Rock wool density: 120kg/m³
|
|
door
|
Steel door, 800*2100mm (can be customized)
|
|
window
|
Pvc/aluminum alloy frame water proof sliding window
Double-layer vacuum glass window with fly screen
Size：800*1000mm (can be customized)
|
|
electric
|
Electric wire are concealed installed inside the top frame and wall panel at factory
|
|
down pipe
|
4 set UPVC pipe inside the colum
|
|
sanitary ware
|
With drainage system embedded inside the bottom frame
|
|
wind resistance
|
Grade 10
|
|
seismic resistance
|
Grade 8
|
|
Insulation ability
|
-50℃-50℃
|
|
Service life
|
50 years
|
