Quick Details
-
Model Number:
-
EW-02A
-
Certificate:
-
ISO,CE
-
Warranty:
-
One year
-
Wire Type:
-
BVR
-
Drive system:
-
Four wheels ,Electric
-
Power plug:
-
European,USA,Chinese plug
-
Wire range:
-
0.1-4.5 mm2 (AWG11-AWG32)
-
Electrical connection:
-
AC110/220V/50/60HZ 200W
-
Wire material:
-
PVC , Braided ,Fiberglass Wire
-
Cutting length:
-
1-9999mm
-
Cutting tolerance:
-
0.002*L) (L = Cutting Length)
Quick Details
-
Usage:
-
Wire Stripping&Cutting
-
Place of Origin:
-
China
-
Brand Name:
-
EW
-
Model Number:
-
EW-02A
-
Certificate:
-
ISO,CE
-
Warranty:
-
One year
-
Wire Type:
-
BVR
-
Drive system:
-
Four wheels ,Electric
-
Power plug:
-
European,USA,Chinese plug
-
Wire range:
-
0.1-4.5 mm2 (AWG11-AWG32)
-
Electrical connection:
-
AC110/220V/50/60HZ 200W
-
Wire material:
-
PVC , Braided ,Fiberglass Wire
-
Cutting length:
-
1-9999mm
-
Cutting tolerance:
-
0.002*L) (L = Cutting Length)
|
Model |
EW-02A |
|
Wire material |
PVC, fiberglass etc. |
|
Conductor cross-section |
0.1 - 4.5 mm² (32 - 11 AWG) |
|
Cutting length |
1 - 9999 mm |
|
Cutting length tolerance |
0.002 * L |
|
Stripping length |
Side I: 0 - 35 mm |
|
Side II: 0 - 15 mm |
|
|
Maximum guide tube diameter |
6 mm |
|
Productivity |
50 - 133 pcs./min |
|
Noise level |
< 70 dB(A) |
|
Power supply |
110, 220 V (50 - 60 Hz) |
|
Power |
200 W |
|
Weight |
31 kg |
|
Dimension |
388.6 * 350.5 * 254 mm |
