Quick Details
-
Weight:
-
200 KG
-
Place of Origin:
-
Henan, China
-
Voltage:
-
380v, 50hz, 3phases, 380V, 50HZ, 3phases
-
Power:
-
1.5kw+7.5kw+1.5kw
-
Key Machines:
-
cassava starch making machine, cassava washing peeling machine, cassava crushing machine
-
Product Type:
-
food processing machine
-
Product name:
-
cassava starch processing machine
-
Application:
-
sweet potato, potato, cassava etc.
-
Function:
-
making starch powder
-
Capacity:
-
1t/h 2t/h 5t/h
-
Warranty:
-
1 year quality warranty
-
Transport:
-
by sea or by air
-
Package:
-
plywood case
-
MOQ:
-
1 SET
-
Keywords:
-
cassava starch making machine
Quick Details
-
Machinery Capacity:
-
4~5t/hour
-
Brand Name:
-
Zhengzhou pasen
-
Dimension(L*W*H):
-
2500*1100*900mm
-
Weight:
-
200 KG
-
Place of Origin:
-
Henan, China
-
Voltage:
-
380v, 50hz, 3phases, 380V, 50HZ, 3phases
-
Power:
-
1.5kw+7.5kw+1.5kw
-
Key Machines:
-
cassava starch making machine, cassava washing peeling machine, cassava crushing machine
-
Product Type:
-
food processing machine
-
Product name:
-
cassava starch processing machine
-
Application:
-
sweet potato, potato, cassava etc.
-
Function:
-
making starch powder
-
Capacity:
-
1t/h 2t/h 5t/h
-
Warranty:
-
1 year quality warranty
-
Transport:
-
by sea or by air
-
Package:
-
plywood case
-
MOQ:
-
1 SET
-
Keywords:
-
cassava starch making machine
Product Introduction
Best price cassava flour making machine corn starch machine sweet potato washing peeling machine
This machine line can be used for processing potato, sweet potato, taro, pueraria, lotus root starch etc.
We have different model of machine for different capacity requirement.
The whole machine line including washing peeling machine, slurry separator, vacuum dewatering machine.
Working principle of sweet potato washing peeling machine
After the starch raw material is sent into the feeding port, it is crushed into filaments under the action of the licker-in roller, and then brought into the cone grinding seat. Driven by the screw shaft, it is squeezed into the narrow gap formed by the inner shell of the cone mill, and the material is further squeezed, crushed and ground under the rotation of the inner shell of the cone mill, so that the starch is released from the fiber. After the ground material is squeezed into the separation cylinder, it is fully mixed with water under the action of the stirring shaft. The free starch dissolves in the water, flows out through the separation sieve and is collected for use. The remaining dross is pushed by the stirring shaft and is Push it out of the separation cylinder.
Product Paramenters
|
Model
|
PSQX-1
|
PXQX-2
|
PSQX-3
|
PSQX-4
|
|
Capacity
|
1 ton/h
|
2~3 ton/h
|
3 ton/h
|
4~5ton/h
|
|
Water consumption
|
5m3/h
|
6m3/h
|
8m3/h
|
9m3/h
|
|
Power
|
1.5kw
|
2.2kw
|
1.5kw
|
2.2kw
|
|
Voltage
|
380v, 50hz, 3phases
|
380v, 50hz, 3phases
|
380v, 50hz, 3phases
|
380v, 50hz, 3phases
|
|
Machine weight
|
240kg
|
310kg
|
360kg
|
380kg
|
|
Machine size
|
2300*550*750mm
|
3200*550*750mm
|
2100*700*1000mm
2000*650*500mm
|
2600*800*1100mm
2000*650*500mm
|
Cassava slurry separator machine
|
Model
|
PSS1
|
PSS2
|
PSS3
|
PSS4
|
|
Capacity
|
1ton/h
|
2ton/h
|
3ton/h
|
4ton/h
|
|
Water consumption
|
1m3
|
5~6m3
|
10m3
|
12m3
|
|
Starch rate
|
95%
|
98%
|
98%
|
98%
|
|
Power
|
2.2kw
|
5.5kw
|
7.5kw
|
11kw
|
|
Voltage
|
220v, 50hz, 1phase
|
380v, 50hz. 3phases
|
380v, 50hz, 3phases
|
380v, 50hz, 3phases
|
Application product
