Henan Mingjie Environmental Equipment Co., Ltd is a high-tech environmental enterprise, covering R&D, manufacturing , sales and exporting, We are committed to provide comprehensive solution for solid waste recycling, specializing in waste tires, waste plastics, and oil sludge reprocessing equipment, to get fuel oil and other renewable energy. With more than 20 years manufacturing experience, a professional team for foreign trade and after-sale service, we take “ To Create Sustainable value for clients “ as pursuit. With abundant experience and foreseeing ability of this industry, we will continuously provide excellent service for clients. All the products from Mingjie have been certified by CE and ISO, have been exported to Canada, Ireland, Czech Republic, Egypt, Brazil, Philippines, Korea, Jordan , Thailand, Malaysia, and England etc, has very stable clients and good reputation in Chinese market, Mingjie company will continuously to create value for our clients , strive to be the No.1 in the industry.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
380V/Optional
-
Power (kW):
-
40 kW
-
Weight (KG):
-
50000 KG
-
Name:
-
pyrolysis plant
-
Operation:
-
Semi Continuous
-
Raw Materials:
-
Waste Tire/Waste Plastic/MSW/Medical Waste
-
Final Products:
-
Pyrolysis Oil/Carbon Black/Syngas
-
Fuel:
-
Natural Gas/LPG/Diesel/Coal/Pyrolysis Oil
-
Reactor Materail:
-
Q245R Boiler Steel/ Optional
-
Reactor Size:
-
D2.8m * L7.1m
-
Colour:
-
Customized
-
Certification:
-
CE, ISO
-
Related Services:
-
Installation And Test Guidance
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Mingjie
-
Core Components:
-
Pyrolysis Reactor, Integrated Condenser
-
Voltage:
-
380V/Optional
-
Power (kW):
-
40 kW
-
Weight (KG):
-
50000 KG
-
Name:
-
pyrolysis plant
-
Operation:
-
Semi Continuous
-
Raw Materials:
-
Waste Tire/Waste Plastic/MSW/Medical Waste
-
Final Products:
-
Pyrolysis Oil/Carbon Black/Syngas
-
Fuel:
-
Natural Gas/LPG/Diesel/Coal/Pyrolysis Oil
-
Reactor Materail:
-
Q245R Boiler Steel/ Optional
-
Reactor Size:
-
D2.8m * L7.1m
-
Colour:
-
Customized
-
Certification:
-
CE, ISO
-
Related Services:
-
Installation And Test Guidance
Product Paramenters
|
Item
|
|
Content
|
|
|
|||
|
Model
|
No.
|
Capacity
|
Reactor Size
|
Operation
|
|||
|
|
MJ-2
|
1-2T Per Batch
|
1400*4000mm
|
Batch
|
|||
|
|
MJ-6
|
6T/D
|
2200*6000mm
|
|
|||
|
|
MJ-10
|
8-10T/D
|
2600*6600mm
|
|
|||
|
|
MJ-12
|
12T/D
|
2800*7100mm
|
|
|||
|
|
MJ-15
|
13-15T/D
|
2800*8000mm
|
|
|||
|
|
MJL-15
|
16-20T/D
|
2800*7100mm
|
Semi-continuous
|
|||
|
|
MLL-20P
|
30T/D
|
1600*26000mm
|
Fully continuous
|
|||
|
|
MLL-30T
|
35-40T/D
|
1600*26000mm
|
Fully continuous
|
|||
|
Accepted materials
|
|
Waste tires/plastics, rubber/oil sludge/MSW/Medical Waste
|
|
|
|||
|
End products
|
|
Pyrolysis oil, carbon black, steel wires , combustible gas
|
|
|
|||
|
Applicable fuel
|
|
Coal/natural gas/LPG/ Diesel/wood/pyrolysis oil
|
|
|
|||
|
Thickness of Reactor
|
|
16mm/18mm
|
|
|
|||
|
Cooling
|
|
Water Cooling
|
|
|
|||
|
Land Required
|
|
300-400m2
|
|
|
|||
Applicable Materials
Comparison of different Operations
|
No
|
Operation
|
Description
|
|
1
|
Batch
|
Capacity 2T-15T per day, low investment cost, can be loaded with whole tires, no need for shredding.
Auto screw carbon discharging, no dust flying, high efficiency.
Modular design condenser, more convenient for installation and transportation. Furnace door (shape and size) can be designed based on client requirement.
Special emission purification system.
|
|
2
|
Semi-continuous
|
Capacity 15-16T per day, auto feeding system, materials needs to be shredded smaller than 50mm.
Loading under high-temperature, no need to wait for reactor cooling ,Fully enclosed production system.
Auto screw carbon discharging, no dust flying, high efficiency.
Special emission purification system.
|
|
3
|
Fully Continuous
|
Capacity 20-45T tires per day, materials needs to be smaller than 20mm. Auto feeding and auto carbon discharging 24 hour per day.
Whole equipment adopt modular design, assembled in fabrication factory, greatly shorten installation period.
No need for foundation, easy to be transported to another project.
Fully enclosed production, special sealing system to guarantee safety of operation, no bad smell generated, no dust flying.
Special emission purification system.
|
