Quick Details
-
Production Rate:
-
100%
-
Voltage:
-
220V/380V/440V
-
Power:
-
100W, 220V/380V/440V
-
Weight:
-
500kg
-
Dimension(L*W*H):
-
1250*1100*1500mm
-
Warranty:
-
one year
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Oxygen Concentrator 20 Lpm
-
Model:
-
CBO
-
Capacity:
-
3~200Nm3/h
-
Dew point:
-
≤-40℃
-
Purity:
-
95%~98%
-
Output pressure:
-
0.1-0.4Mpa
-
CEM/OEM:
-
YES
-
HS Code:
-
8419601900
-
MOQ:
-
1set
-
Certification:
-
ISO9001:2008
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ChenRui
-
Model Number:
-
PSA oxygen generator
-
Production Rate:
-
100%
-
Voltage:
-
220V/380V/440V
-
Power:
-
100W, 220V/380V/440V
-
Weight:
-
500kg
-
Dimension(L*W*H):
-
1250*1100*1500mm
-
Warranty:
-
one year
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
Oxygen Concentrator 20 Lpm
-
Model:
-
CBO
-
Capacity:
-
3~200Nm3/h
-
Dew point:
-
≤-40℃
-
Purity:
-
95%~98%
-
Output pressure:
-
0.1-0.4Mpa
-
CEM/OEM:
-
YES
-
HS Code:
-
8419601900
-
MOQ:
-
1set
-
Certification:
-
ISO9001:2008
Description of
Oxygen Concentrator 20 Lpm
| product | PSA oxygen generator |
| Model | CBO |
| Capacity | 3~200Nm3/h |
| Purity | 95%-98% |
| Pressure | 0.1~0.4Mpa |
| Warranty | 1 year |
|
HS CODE |
8419609090 |
| Power | 220/380/440 |
| CEM/OEM | yes |
| MOQ | 1 set |
| dew point | - 40℃ |
Specification
How to read the the specifications?
as we all know, PSA means pressure swing adsorption.
CBN-5A
"CBN" mean psa nitrogen generator
"5" means capacity is 5Nm3/h
"A" means purity is 99.999%.
pressure is from 0.1-0.8Mpa
CBO-5
"CBO" means PSA oxygen generator
"5" means capacity is 5Nm3/h
Purity is from 90-93%
Pressure is 0.1-0.5Mpa
Principle of Operation
oxygen and nitrogen generators are constructed according to the principle of operation P.S.A. (Pressure Swing Adsorption) and are composed by a minimum of two absorbers filled up with molecular sieve.The absorbers are crossed alternatively by the compressed air (previously purified in order to eliminate oil, humidity and powders) and produce nitrogen or oxygen. While a container, crossed by the compressed air, produces gas, the other regenerates itself losing to pressure atmosphere the gases previously adsorbed. The process comes repeated in cyclical way. The generators are managed by a PLC.
Pictures of Oxygen Concentrator 20 Lpm
Equipment Installation Condition
|
Item |
Description |
Remark |
||
|
Power |
250V(380V)/50Hz |
100W |
Power for oxygen Generator |
|
|
250V(380V)/50Hz |
60W |
Power for Heatless Air Dryer |
||
|
Environment Temperature |
≤38℃(good ventilation) |
/ |
||
|
Gas(PSA gas consumption)
|
Capacity |
≥__Nm 3 /min (20℃,101.325kPa) |
Air Compressor Output Requirements |
|
|
Pressure |
≥ 0.8MPa |
|||
|
Temperature |
≤ 50 ℃ |
|||
|
Oil Content |
≤ 3 PPm |
|||
|
Dust Size |
≤ 5 μm |
|||
vpsa oxygen generator >> psa oxygen generator >> membrane nitrogen generator >>
psa nitrogen generator >> liquid nitrogen generator >> psa oxygen generator >>
6 .Technical Features And After Sales Service Commitment
- It is an advanced technology with less investment.
- The quality is reliable and both the N2 purity and quantity are stable.
- The unit is supplied in a skid-mounted manner, which can be transported and installed easily.
- It is full automatic control and no need for operators, easy to start-up and shutdown, simplified and convenient maintenance.
- Our service department is formed by a skilled team of engineers. There are more than 15 of them, whose average age is about 35. We always adhere to the general principle of "good faith, high quality, innovation, and development ", and follow the idea of giving customers the maximum of satisfaction, which laid a good foundation to ensure that the service quality. We obtained loads of compliments for we not only guarantee the service quality, but also the benefits of customers.
- Free warranty for the equipments during the promised period
1. The nitrogen generator,1 year warranty, maintenance responding time is less than eight hours.
2. Ancillary equipment ,1 year warranty, maintance responding time is less than 8 hours.
3. Lifelong maintance service in a timely manner, the responding time is less than 8 hours.
4.Provide 24-hour hotline service. 0086-18757180256
5.Return visit every six months (callback or on the spot).
6.Supply accessories in a timely manner, the delivery time is generally 1-7 days.
7.Free repair at the expiry time of warranty
We have been making series of air separation units for nearly 20 years. With the support of a perfect management system and advanced manufacturing tools, we make constant technological improvements. We have built long-term good cooperation with many design and research institutes. Our air separation units have better and better performance.
Our company has passed ISO9001:2008 certification. We have won many honors. The strength of our company is constantly growing.
We warmly welcome all of our customers to build win-win cooperation with us.
Send Inquiry Please bring the following description, we have more models to recommend to you ~!
Thank you~!
| Technical Information | Your Kind Requirement |
| Capacity | _________Nm³/h |
| Purity | _________% |
| Outlet Pressure | _________Mpa or Bar |
| Power | ________V/HZ |
