Quick Details
-
Model Number:
-
PPM-T222H
-
Material:
-
Stainless Steel
-
Accuracy:
-
0.5%FS, 0.5%FS
-
Name:
-
Stainless Steel Pressure Sensor Transducer 50 Bar 100Bar 300Bar
-
Measuring medium:
-
Gas, liquid
-
Pressure type:
-
Gauge pressure(G), Sealed pressure(S)
-
Pressure range:
-
0~400bar
-
Power supply:
-
9-32VDC
-
Output signal:
-
4~20mA ,0~10VDC,0~5VDC
-
Medium temp:
-
-40~+85℃
-
Overpressure:
-
150%FS (1.5 times FS)
-
Damage pressure:
-
500%FS (5 times FS)
Quick Details
-
Warranty:
-
1 years
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Tecnk
-
Model Number:
-
PPM-T222H
-
Material:
-
Stainless Steel
-
Accuracy:
-
0.5%FS, 0.5%FS
-
Name:
-
Stainless Steel Pressure Sensor Transducer 50 Bar 100Bar 300Bar
-
Measuring medium:
-
Gas, liquid
-
Pressure type:
-
Gauge pressure(G), Sealed pressure(S)
-
Pressure range:
-
0~400bar
-
Power supply:
-
9-32VDC
-
Output signal:
-
4~20mA ,0~10VDC,0~5VDC
-
Medium temp:
-
-40~+85℃
-
Overpressure:
-
150%FS (1.5 times FS)
-
Damage pressure:
-
500%FS (5 times FS)
Application of 0-5V Submersible Liquid Water Pressure Sensor
Mechanical engineering Industry
Industrial automation measuring
Hydraulic and level measurement
Gas tank pressure monitoring
Industrial test and control
Other industrial applications
Special Feature of 0-5V Submersible Liquid Water Pressure Sensor
Widely pressure range from 0~ 400bar
Various electrical connectors available: can be OEM custom various parameters
Various industrial standard signal output:4~20mA,0~10V,0~5V,1~5V,0.5~4.5V optional
Wide temperature range: -40 ~ 125℃, autocorrection temperature drift
Moisture-proof design: Stable performance in very humid environment
Harsh working environment without delay: Response time ≤1ms
Compact dimension design
Description of 0-5V Submersible Liquid Water Pressure Sensor
PPM-T222H Series standard pressure transmitter adopts Classical diaphragm technology. It designed with widely pressure range, compound output signals optional. It is suitable for both civil and industrial use. Multiply construct available, it can make sure the batch requirement of the client, we also can supply the special design.
PPM-T222H Pressure Transmitter
1. Measuring range from 0-250Bar .
2. Output signal : 0.5-4.5V
3. Process connection: G1/4
4. Power Supply: 5Vdc
5. Accuracy: 0.5%FS
Remarks: The price is based on the above specification . For this model other specification please contact us . Other pressure range etc specification such as this model are list as follows:
Specifications
| Measuring medium | Gas, liquid |
| Pressure type | Gauge pressure(G), Sealed pressure(S) |
| Pressure range | 0~400bar |
| Power supply | 9-32VDC |
| Output signal | 4~20mA ,0~10VDC,0~5VDC |
| Nonlinearity | ≤0.2 |
| Non-repeatability | ≤0.2% FS |
| Accuracy | 0.5%FS |
| Long-term stability | 0.25%FS/year |
| Medium temp | -40~+85℃ |
| Operation temp | -40~+85℃ |
| Zero temp. drift | ≤0.03%FS/℃ |
| FS temp. drift | ≤0.03%FS/℃ |
| Response time | ≤5ms(10%-90%)with buffering ≤1ms(10%-90%) Without buffering |
| Insulation resistance | ≥1000 MΩ/100V |
| Overpressure | 150%FS (1.5 times FS) |
| Damage pressure | 500%FS (5 times FS) |
| Vibration resistance | 5~1000Hz |
| Shock resistance | 50g, 20ms |
| Process connections | G1/4, M14×1.5, or other process connections on request |
| Materials | Wetted parts: 17-4PH, non-wetted parts: stainless steel 304 |
| Ingress protection | IP67 |
| Electrical connections | Circular connector M12 x 1,L-connector DIN43650 |
Dimensions in mm
Wiring diagram
