Quick Details
-
Board Size:
-
1500x1200mm
-
Model Number:
-
ak1025675
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
akeson
-
Copper Thickness:
-
Hoz-10oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm
-
Min. Line Spacing:
-
0.1mm
-
Surface Finishing:
-
Immersion gold
-
Item::
-
12L PCB
-
Layers:
-
1-40L
-
Solder Mask Color:
-
Green Oil;Red;Yellow.Optional
-
Product name:
-
Good Quality pcb Factory Directly
-
PCB Item:
-
Electronic OEM PCB Making Machine
-
Usage:
-
Vacuum Packing Standard circuit board
-
Material:
-
FR4/CEM-1/CEM-3/FR1/aluminum
-
PCB Test:
-
100% Electronic Testing
-
Service type:
-
OEM.ODM DIP SMT
Quick Details
-
Number of Layers:
-
1-40Layers
-
Base Material:
-
FR-4
-
Board Thickness:
-
1.0mm
-
Board Size:
-
1500x1200mm
-
Model Number:
-
ak1025675
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
akeson
-
Copper Thickness:
-
Hoz-10oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm
-
Min. Line Spacing:
-
0.1mm
-
Surface Finishing:
-
Immersion gold
-
Item::
-
12L PCB
-
Layers:
-
1-40L
-
Solder Mask Color:
-
Green Oil;Red;Yellow.Optional
-
Product name:
-
Good Quality pcb Factory Directly
-
PCB Item:
-
Electronic OEM PCB Making Machine
-
Usage:
-
Vacuum Packing Standard circuit board
-
Material:
-
FR4/CEM-1/CEM-3/FR1/aluminum
-
PCB Test:
-
100% Electronic Testing
-
Service type:
-
OEM.ODM DIP SMT
|
Item
|
Multilayers PCB High Density Circuit Board
|
|
Layer count
|
1-30 layers
|
|
Material
|
FR4(High TG, Halogen Free, high frequency), CEM1, CEM3,BT,Al base mateiral,and so on.
Supplier: SY,KB,ITEQ,Isola,Nelco,Rogers,Grance,Mitsui
|
|
Maxpanel size
|
32±20(800mm±508mm)
|
|
Min width/space(min)
|
4mil/4mil
|
|
Max copper weight
|
140um(4oz) for inner layer
175um(5oz) for outer layer
|
|
Min machine drill size
|
0.2mm(8mil)
|
|
Via hole tpye
|
Blind/Burried/plugged
|
|
Thickness of finished board
|
0.20-6.0mm
|
|
Tolerance
|
Registration of innerlayer to of innerlayer:±3mil
Accuracy of hole position:±2mil
Tolerance of dilled slot:±3mil
Tolerance of PTH diameter:±3mil
Tolerance of NPTH diameter:±2mil
PTH hole copper thichness: 0.4-2mil
Image to image tolerance:±3mil
Tolerance of etching:±1mil
Solder mask registration tolerance: ±2mil
Finished board : Thickness<=1.0mm: +/-0.1mm
Thickness>0.1mm:+/-10%
Outline router: +/-0.1mm
Outline Score: +/-0.2mm
|
|
Color of solder mask
|
Green, Black, Blue,Red, White and so on
|
|
Surface freatment
|
HASL,HASL Lead Free,OSP ,Immersion Gold, Immersion Ti, Immersion Sliver, Flash gold, Selective Gold plating(gold thicness up to 120u),Gold figers ,Carbon print, Peelabe Mask
|
|
Hardness of solder solder
|
>=6H
|
|
Outline finished
|
CNC, V-CUT, Punching
|
|
Peel strength of line
|
≥61B/in
|
|
Warp and twist
|
≤0.7%
|
Deliverables
1/Quotes in 24 hours or less
We support OEM orders, No MOQ for any order, sample order also welcomed.
2/Standard production leadtime of 12 working days (2 weeks)
3/Prototype leadtime of 5 to 10 working days (1-2 weeks)
4/Stack-ups and impedance simulation in 36 hours
5/Initial response to technical questions or quality concerns in 36 hours
6/DFM and EQ's prior to PO placement upon request
7/We have 10 SMT lines and 3 DIP lines, more than 400 workers.
8/Our main production has IoT&Gateway, Medical, Security, Consumer, LED, industrial control,
we are able to make all of PCBA which you can provide Gerber file and BOM.
Quality system
1/Akeson has mature and stringent Q
2/100% AOI, 100% ET, 100% FQC + FQA
3/SPC and Cpk programs
4/Lean Manufacturing and 6S programs
5/Advanced inspection and lab equipment
6/Standard QA report with every shipment
7/RoHS and REACH Compliance
8/Conflict Minerals Compliance
