- The silicone rubber heater's max wattage can be made for 1 w/cm²;
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
DM
-
Weight:
-
1.6 KG
-
Working Temperature Range:
-
5 - 180 ℃
-
Core Components:
-
HEATING WIRE
-
Insulation Material:
-
Silicone rubber
-
Heating material:
-
etched metal foil
-
Insulating Resistance:
-
≥50MΩ
-
Power deviation:
-
±5%
-
Thickness:
-
0.5-4 mm
-
Maximum size:
-
1000*4000mm
-
Size deviation:
-
10.±0.5%
-
Wire length:
-
customized
-
Controller:
-
Thermostat / Digital
-
Application:
-
Oil Drum / Gas Cylinder / Glue Barrel
Quick Details
-
Type:
-
Band Heater
-
Power Source:
-
Electric
-
Voltage:
-
12-480v
-
Place of Origin:
-
China
-
Brand Name:
-
DM
-
Weight:
-
1.6 KG
-
Working Temperature Range:
-
5 - 180 ℃
-
Core Components:
-
HEATING WIRE
-
Insulation Material:
-
Silicone rubber
-
Heating material:
-
etched metal foil
-
Insulating Resistance:
-
≥50MΩ
-
Power deviation:
-
±5%
-
Thickness:
-
0.5-4 mm
-
Maximum size:
-
1000*4000mm
-
Size deviation:
-
10.±0.5%
-
Wire length:
-
customized
-
Controller:
-
Thermostat / Digital
-
Application:
-
Oil Drum / Gas Cylinder / Glue Barrel
Products Description
Specification
|
Technical Parameter
|
|
|
|
|||
|
Rated power
|
w
|
Lead length
|
300mm standard, customizable
|
|||
|
Rated voltage
|
12v-480v
|
Wire tension
|
15N *15N
|
|||
|
Maximum size
|
1000-1200mm
|
Minimum size
|
20mm *20mm
|
|||
|
Ambient Temperature
|
-60-250℃
|
Highest temperature
|
250℃
|
|||
|
Maximum thickness
|
1.5mm-4mm
|
Withstand voltage
|
1.5KV
|
|||
|
Insulation resistance
|
≥5MΩ
|
Size deviation
|
±0.5%
|
|||
|
Power deviation
|
±5%
|
Wire type
|
Silicone braided wire
|
|||
|
Accessories options for heating pads
|
|
|
|
Thermocouple
|
K / J / withouut
|
|
|
Controller
|
Dial / Digital / Anti-explosion
|
|
|
Plug
|
American Standard / European Standard / British Standard
|
|
Details Images
Advantages
- The silicone rubber heater can improve heat transfer, accelerate warming and decrease power under the process of operation;
- The silicone rubber heater's can be made for any size and any shapes.
1.What wattage and voltage will be used?
2.What is the shape and size?
3.What is the lead wire length?
Standard specifications for Oil Tank and Gas Tank
|
Product Name
|
Size
|
Power
|
Voltage
|
|
5KG Gas tank
|
760*80mm
|
200w
|
220v/380v
|
|
10KG Gas tank
|
970*80mm
|
270W
|
220v/380v
|
|
15KG Gas tank
|
970*120mm
|
400W
|
220v/380v
|
|
50KG Gas tank
|
1250*120mm
|
450W
|
220v/380v
|
|
50KG Gas tank
|
1250*200mm
|
800W
|
220v/380v
|
