Quick Details
-
Output:
-
29.4V/4A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Quawin/OEM
-
Model Number:
-
QW259-040-L
-
Output Power:
-
120W
-
Input:
-
90-264VAC 47/63Hz
-
Efficiency::
-
>=85%
-
Charge mode::
-
CC---CV---Float Charge
-
Output voltage:
-
29.4V
-
Output current:
-
4a(Max)
-
Output power:
-
117.6W
-
Dimensions (mm):
-
172.7*72.7*36
-
Weight:
-
600±10g(only body)
-
Warranty:
-
12 months
Quick Details
-
Type:
-
Desktop
-
Use:
-
Standard Battery, scooter, PROFESSIONAL, Industrial, electric car, electr bike
-
Is LED Lamp Illumination:
-
NO
-
Output:
-
29.4V/4A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Quawin/OEM
-
Model Number:
-
QW259-040-L
-
Output Power:
-
120W
-
Input:
-
90-264VAC 47/63Hz
-
Efficiency::
-
>=85%
-
Charge mode::
-
CC---CV---Float Charge
-
Output voltage:
-
29.4V
-
Output current:
-
4a(Max)
-
Output power:
-
117.6W
-
Dimensions (mm):
-
172.7*72.7*36
-
Weight:
-
600±10g(only body)
-
Warranty:
-
12 months
Quick Detail:
Brand Name:QUAWIN
Model Number:QW259-040-L
Use:7S 24V 25.2V 25.9V lithium ion or polymer battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Battery charger:automatic battery charger 29.4V
Color:Black
Shell Material:Plastic Shell(ABS+PC)
Input voltage:90-264VAC 47/63Hz
Output voltage:29.4V
Output current:4a(Max)
Output power:117.6W
Shock & Vibration:SAEJ1378 Standard
Output Connector:DC Jack,Waterproof Flat Jack,RCA,Multiple PIN,Micro USB,TYPE C,Small Alligator Clip,Ring Type Terminal,Air Jet Plug,Audio frequency connector,customization
Packaging & Delivery:
Inner package:Corrugated box,EPE pearl cotton/according to your requirements
Outer packing: export carton
Delivery Detail:sample within 7 work days,25-35 days for bulk order
Specifications:
7S 24V 25.2V 25.9V lithium ion or polymer battery pack
Features:
• Fully auto CC +CV(H)+CV(L) charging process;
• Constant big charging current for faster charging;
• Automatically charging ending with Cut-Off output;
• Fully enclosed fanless design, quiet and durable.
• Efficiency(at 100% load):>=92%
• Operating temperature:-20℃ ~ 45℃
• Storage temperature:-40℃ ~ 85℃
• Operating humidity:5%~90%RH
Specification:
• Input: 90-264VAC 47/63Hz
• Output: DC 29.4V
• Charging current: 4a(Max)
• Dimensions (mm): 172.7*72.7*36
• Weight: 600±10g(only body)
Safety protections:
• Over current protection
• Over voltage protection
• Short circuit protection
• Anti-revert current protection
LED Indicator:
The charger turn trickle-off charging mode if battery is full (1/10C), and indicate by LED:
• Charging:Red LED
• Battery Full:Green LED
• Error: RED Light Flashing
Call us to know more details datasheet.
|
Model |
Input Voltage (V) |
Battery Voltage (V) |
Charging Voltage (V) |
Charging Current (A) |
|
|
QW128-070-F |
LiFePO4 |
AC 100~264V |
12.8(4S) |
14.6 |
7 |
|
QW256-040-F |
25.6(8S) |
29.2 |
4 |
||
|
QW480-020-F |
38.4(12S) |
43.8 |
2.5 |
||
|
QW512-020-F |
51.2(16S) |
58.4 |
2 |
||
|
QW640-015-F |
64(20S) |
73 |
1.5 |
||
|
QW768-014-F |
76.8(24S) |
87.6 |
1.4 |
||
|
QW185-060-L |
Lithium |
14.8(4S) |
16.8 |
7 |
|
|
QW259-040-L |
25.9(7S) |
29.4 |
4 |
||
|
QW370-025-L |
37(10S) |
42 |
2.5 |
||
|
QW481-020-L |
48.1(13S) |
54.6 |
2 |
||
|
QW629-015-L |
62.9(17S) |
71.4 |
1.5 |
||
|
QW740-014-L |
74(20S) |
84 |
1.4 |
||
|
QW120-070-S |
Lead Acid |
12(1S) |
14.7 |
7 |
|
|
QW240-040-S |
24(2S) |
29.4 |
4 |
||
|
QW360-025-S |
36(3S) |
44.1 |
2.5 |
||
|
QW480-020-S |
48(4S) |
58.8 |
2 |
||
|
QW600-015-S |
60(5S) |
73.5 |
1.5 |
||
|
QW720-014-S |
72(6S) |
88.2 |
1.4 |
||
