Quick Details
-
Size:
-
9500/12471 x 2438 x 1258 mm
-
Place of Origin:
-
Guangdong, China
-
Name:
-
container chassis sale
-
Axle:
-
11 ton, diameter 127 mm, 2/3 units
-
Suspension:
-
Mechanical/Air suspension
-
King pin:
-
2", welding type
-
Landing gear:
-
28 ton, two speeds
-
Tire:
-
255/70R22.5, 16 PR, 8/12 units
-
Rim:
-
8.25-22.5, 8/12 units
-
ABS:
-
None
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
30 tons
-
Brand Name:
-
STD
-
Size:
-
9500/12471 x 2438 x 1258 mm
-
Place of Origin:
-
Guangdong, China
-
Name:
-
container chassis sale
-
Axle:
-
11 ton, diameter 127 mm, 2/3 units
-
Suspension:
-
Mechanical/Air suspension
-
King pin:
-
2", welding type
-
Landing gear:
-
28 ton, two speeds
-
Tire:
-
255/70R22.5, 16 PR, 8/12 units
-
Rim:
-
8.25-22.5, 8/12 units
-
ABS:
-
None
SPECIFICATION
|
Specification
|
|
|
|
1. Dimension
|
Type A: 9500 x 2438 x 1258 mm (Extended: 12471 x 2438 x 1258 mm)
Type B: 9540 x 2438 x 1258 mm (Extended: 12392 x 2438 x 1258 mm)
|
|
|
2. The chassis with a slider, can be extended approximately 2970/2850 mm by pneumatic lock pin
|
|
|
|
3. Multiple loading models
|
Loaded 20' or 40' container or two empty 20' container
|
|
|
Standard Configuration
|
|
|
|
1. Axle
|
11 ton, diameter 127 mm, 2/3 units
|
|
|
2. Suspension
|
Mechanical/Air suspension
|
|
|
3. King pin
|
2", welding type
|
|
|
4. Landing gear
|
28 ton, two speeds
|
|
|
5. Tire
|
255/70R22.5, 16 PR, 8/12 units
|
|
|
6. Rim
|
8.25-22.5, 8/12 units
|
|
|
7. Braking system
|
Chinese local brand
|
|
|
8. Electrical system
|
Chinese local brand, 7-way split pin receptacle plug, LED light
|
|
|
9. ABS
|
None
|
|
|
10. Painting
|
Polyurethane, colour supplied by customer
|
|
|
11. Mudguard
|
Chinese local brand
|
|
|
Optional Configurations
|
|
|
|
1. Air suspension
|
Firestone or Goodyear
|
|
|
2. Lift axle system
|
Lift axle system
|
|
|
3. ABS system Wabco
|
ABS system Wabco or Chinese brand
|
|
