Quick Details
-
Brand Name:
-
H3C
-
Model Number:
-
S5024X-HPWR-EI
-
Place of Origin:
-
GUA
-
Product Name:
-
Ethernet Switch
-
Port:
-
24+4
-
Power:
-
AC110V/220V@50HZ/60HZ
-
PoE power supply:
-
30W / 370W max
-
Working temperature:
-
-5C~45C
-
Humidity:
-
5%~90% non-condensing
-
Machine leakage current:
-
Meet UL 62368-1/EN 62368-1 standard
-
Fire Requirements:
-
Meet UL62368-1/EN62368-1/IEC62368-1/ standard.
-
Weight:
-
≤ 3.5kg
-
Certification:
-
CE RoHS FCC
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
336Gbps
-
Brand Name:
-
H3C
-
Model Number:
-
S5024X-HPWR-EI
-
Place of Origin:
-
GUA
-
Product Name:
-
Ethernet Switch
-
Port:
-
24+4
-
Power:
-
AC110V/220V@50HZ/60HZ
-
PoE power supply:
-
30W / 370W max
-
Working temperature:
-
-5C~45C
-
Humidity:
-
5%~90% non-condensing
-
Machine leakage current:
-
Meet UL 62368-1/EN 62368-1 standard
-
Fire Requirements:
-
Meet UL62368-1/EN62368-1/IEC62368-1/ standard.
-
Weight:
-
≤ 3.5kg
-
Certification:
-
CE RoHS FCC
| Attribute | S5024X-HPWR-EI |
| Switching capacity | 240Gbps |
| Packet forwarding rate | 104Mpps |
| Management port | / |
| Ports description | 24 10/100/ 1000Base-T Ethernet ports |
| 4 1000/10000Base-X SFP optical port | |
| Electrical port attribute | Half-duplex, full-duplex, and auto-negotiation |
| MDI/MDI-X | |
| Ethernet features |
IRF2
Static MAC configuration
|
| IPv6 |
Support IPv6 static routing, bidirectional protocol stack
Support DHCPv6 Client, DHCPv6 Snooping Support ND, PMTU Support IPv6 Ping, IPv6 Telnet, IPv6 SSHv2, IPv6 DNS |
| DHCP |
DHCP Client DHCP Snooping DHCP Relay DHCP Option82 |
| QoS/ACL |
Packet filtering
SP/WRR/SP+WRR queue scheduling Two-way ACL Port-based rate limiting flow-based redirection Support time period |
| Security |
User level management and password protection SSH2.0 Port isolation 802.1X Port security MAC address certification IP Source Guard HTTPs |
| Network management and monitoring |
Web page configuration
Uploading and downloading management of FTP, TFTP, and Xmodem files |
| System management |
Uploading and downloading of FTP, TFTP, Xmodem, and SFTP files
SNMP V1/V2c/V3 NTP clock System operating logs |
| Lightning protection level | 6 kV |
| PoE+ power | Support |
| Weight | ≤ 6 kg |
| Device power consumption | ≤ 467W |
| Temperature | Operating temperature: -5°C to 45°C |
| Input voltage | AC: 100 V to 240 V, 50/60 Hz |
We support DHL, FedEx, UPS, Aramex etc express for small quantity.
For big quantity we suggest air and sea shipment.
It is welcome if you are going to ship parcels through your cooperated forwarders.
1. Top performance network products.
2. Professional recommendation.
3. Good after-sale service.
