Quick Details
-
Warranty:
-
25 years, 25 years
-
Brand Name:
-
JA
-
Model Number:
-
JAM72S30 530-550/MR
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Solar cell:
-
A grade
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
3.2mm Tempered Low Iron
-
Cable:
-
4mm ^2 300mm PV Cable
-
Wind load, back:
-
2400Pa / 2400Pa
-
Snow load, front:
-
3000Pa / 5400Pa
-
Certificates:
-
TUV CE PID ISO
-
Application:
-
Commercial,Industrial,Home
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.5%
-
Warranty:
-
25 years, 25 years
-
Brand Name:
-
JA
-
Model Number:
-
JAM72S30 530-550/MR
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Solar cell:
-
A grade
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
3.2mm Tempered Low Iron
-
Cable:
-
4mm ^2 300mm PV Cable
-
Wind load, back:
-
2400Pa / 2400Pa
-
Snow load, front:
-
3000Pa / 5400Pa
-
Certificates:
-
TUV CE PID ISO
-
Application:
-
Commercial,Industrial,Home
Product Description
|
TYPE
|
JAM72S30-525/MR
|
JAM72S30-530/MR
|
JAM72S30-535/MR
|
JAM72S30-540/MR
|
JAM72S30-545/MR
|
JAM72S30-550/MR
|
||||||
|
Rated Maximum Power(Pmax) [W]
|
525
|
530
|
535
|
540
|
545
|
550
|
||||||
|
Open Circuit Voltage(Voc) [V]
|
49.15
|
49.3
|
49.45
|
49.6
|
49.75
|
49.9
|
||||||
|
Maximum Power Voltage(Vmp) [V]
|
41.15
|
41.31
|
41.47
|
41.64
|
41.8
|
41.96
|
||||||
|
Short Circuit Current(lsc) (A]
|
13.65
|
13.72
|
13.79
|
13.86
|
13.93
|
14
|
||||||
|
Maximum Power Current(lmp) [A]
|
12.76
|
12.83
|
12.9
|
12.97
|
13.04
|
13.11
|
||||||
|
Module Efficiency [%]
|
20.3
|
20.5
|
20.7
|
20.9
|
21.1
|
21.3
|
||||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
|
||||||
|
STC
|
Irradiance 1000W/m2, cell temperature 25°C, AM1.5G
|
|
|
|
|
|
||||||
|
Remark: Electrical data in this catalog do not refer to a single module and they are not part of the offer.They only serve for comparison among different module types.
|
|
|
|
|
|
|
||||||
Material
Factory
Production Process
Project Cases
What we provide
Packaging & Delivery
FAQ.
What's your payment terms?TT,Letter of Credit,Paypal,Western Union etc. Could you send free sample?
Your sample fee will be returned when your place next order.
Can we print our own logo?
Yes absolutely.
What are the advantages of your company?
We are new factory ,now we control thin benifit for developing customers , price 、quality and service will never let customers down！！
Your sample fee will be returned when your place next order.
Can we print our own logo?
Yes absolutely.
What are the advantages of your company?
We are new factory ,now we control thin benifit for developing customers , price 、quality and service will never let customers down！！
