vehicles, mining machinery, forestry machinery, construction machinery (such as excavators, bulldozers, loaders, road pavers,
cranes, etc.) ) and other heavy loads, the lower the center of gravity, the better the stability and safety
- Product Details
- {{item.text}}
Quick Details
-
Size:
-
15000*3000*1650mm
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Low Bed Trailer
-
Axle:
-
13 Ton Fuwa Brand
-
Tire:
-
12R22.5
-
Suspension:
-
Mechanical Suspension
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Landing Gear:
-
Standard 28Ton
-
Main Beam:
-
Q345B
-
Certification:
-
ce
-
Function:
-
Transport Heavy Duty Equipment
-
Color:
-
Customers Optional
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
60-100tons
-
Brand Name:
-
JianXing
-
Size:
-
15000*3000*1650mm
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Low Bed Trailer
-
Axle:
-
13 Ton Fuwa Brand
-
Tire:
-
12R22.5
-
Suspension:
-
Mechanical Suspension
-
King pin:
-
2"(50mm)or3.5"(90mm)
-
Landing Gear:
-
Standard 28Ton
-
Main Beam:
-
Q345B
-
Certification:
-
ce
-
Function:
-
Transport Heavy Duty Equipment
-
Color:
-
Customers Optional
Hydraulic Extendable Excavator Transport 3 4 axle 40 feet lowboy trailer 40 ton 60 ton 80 ton low loader transport trailer
3 Axles Low-bed Semi-trailer
vehicles, mining machinery, forestry machinery, construction machinery (such as excavators, bulldozers, loaders, road pavers,
cranes, etc.) ) and other heavy loads, the lower the center of gravity, the better the stability and safety
1. Heavy duty ladder, and extra support to prevent ladder from being broken when loading equipment.
2. Optional hydraulic ladder for more than 60 tons capacity,avoiding occupational injury when release ladder by manual operation.
3. Anti-slip strip on tail and rear of platform to ensure loading safely.
4. Optional landing gear under tail to ensure trailer to be stable when loading.
5. H-beam for side beam instead of channel steel.
2. Optional hydraulic ladder for more than 60 tons capacity,avoiding occupational injury when release ladder by manual operation.
3. Anti-slip strip on tail and rear of platform to ensure loading safely.
4. Optional landing gear under tail to ensure trailer to be stable when loading.
5. H-beam for side beam instead of channel steel.
|
General
|
|
|
|
|||
|
Overall Dimension
|
11960mm*3000mm*3300mm
|
|
|
|||
|
Flatbed Dimension
|
8000mm*3000mm
|
|
|
|||
|
Tare Weight
|
9630kg
|
Pay Load
|
80ton
|
|||
|
King Pin Setting
|
450mm
|
Rear Overhang
|
1870mm
|
|||
|
Wheel base
|
7650mm+1305mm+1305mm
|
Loading Surface Height
|
1320mm
|
|||
|
Track
|
2160mm
|
|
|
|||
|
Running Gear
|
|
|
|
|||
|
Suspension
|
Tri-axle 8-pcs leaf spring suspension with equalizer beam
|
|
|
|||
|
Tires
|
311.00-20, 11.00R20,12.00-20,12.00R20 12units
|
|
|
|||
|
Axles
|
AQ，FUWA, BPW or STEYR axle, 13T capacity
|
|
|
|||
|
Brakes
|
Dual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30+T30 air chamber; parking brake
|
|
|
|||
|
Under Frame
|
|
|
|
|||
|
Main Beam
|
I shape, Mild Alloy (16Mn) by Automatic submerged arc welding.
|
|
|
|||
|
Cross Beam
|
Mild Alloy Q235, 16# channel beam
|
|
|
|||
|
King Pin
|
Size: 50# (2'') or 90#(3.5’’); Type: welded or assembled
|
|
|
|||
|
Landing Gear
|
Single side operation or double side operation, Static capacity 30Ton
|
|
|
|||
|
Flatbed Floor
|
Checkered sheet, thickness 4mm
|
|
|
|||
|
Rear Ladders
|
Spring power-assisted
|
|
|
|||
|
Electrical & Paint
|
|
|
|
|||
|
Lights & Reflectors
|
Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
|
|
|
|||
|
Wiring
|
24V, 6 lines
|
|
|
|||
|
Air/Elec. Connector
|
ISO standard air connector, 24V 7 pin plug socket
|
|
|
|||
|
Paint
|
Sand blasting before painting, color upon request
|
|
|
|||
Details Images
Jianxing Green Cattle International Co. Ltd
, a professional customizable manufacturer of semi-trailers.After nearly 20 years of development, our factory has now become a manufacturer trading company.
Our factory mainly produces and sells skeleton semi-trailers, flatbed semi-trailers, and low flatbed semi-trailers, with more than 40 kinds of products. Our factory has dozens of senior technicians and several senior managers to escort the production process. In the product process, we have an advanced spray-baking integrated process to create products with beautiful appearance and
first-class quality. We have our own quality inspection department, product quality can be guaranteed.Our company has been certified by the third-party authoritative organization SGS, and the company's products are exported to Southeast Asia, Central Asia, the Middle East, Africa and other parts of the world. We have our own overseas after-sales service department to solve your after-sales service problems, so that you can buy without worried.
Welcome customers from all over the world to visit and cooperate！
Our company is led by a professional manager who have been in the same industry for more than 15 years. So we have a perfect training mechanism, perfect foreign trade process, reasonable risk aversion rules, rich foreign trade business experience. The company' s philosophy is concentric share with win-win, grateful for you and the service attitude is every trust must not be disappointed. Welcome partners from all over the world to visit and negotiate business with us.
We usually adopt shipping by bulk cargo, flat rack, container container and Roro ship. We will arrange the most cost-effective transportation mode according to the quantity of products. All trailers will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
3 sets stacked, and the whole trailer will be waxed before shipment, it can prevent our trailers suffering from seawater corrosion during the shipping.
We will transport our trailers by bulk cargo carrier, RO-RO ship or 40/45 HQ
Certification
1.Advantages of low bed semi-trailer
* carrying heavy cargo.When transporting heavy cargo, you can transport super high cargo.
* mainly used for medium and long-distance transportation.
* load capacity ranges from 60to 100 tons based on client requirements
* beam can be flat type or Gooseneck type
* carrying heavy cargo.When transporting heavy cargo, you can transport super high cargo.
* mainly used for medium and long-distance transportation.
* load capacity ranges from 60to 100 tons based on client requirements
* beam can be flat type or Gooseneck type
2.Why choose us
* factory direct, no middle man, no agency fees, therefore low price for high quality only from us.
* directly manufactured from our own factory,can be customized for various needs
* cutting edge automation equipment adopted in the factory, improved quality from traditional production methods
* steel welded by automatic submerged arc process, connection spots look flawless, more solid and durable compared with traditional manual ways.
* cover painting is more sustainable, corrosion-resistant, uniform and smooth, using sand blasting powder painting process
* factory direct, no middle man, no agency fees, therefore low price for high quality only from us.
* directly manufactured from our own factory,can be customized for various needs
* cutting edge automation equipment adopted in the factory, improved quality from traditional production methods
* steel welded by automatic submerged arc process, connection spots look flawless, more solid and durable compared with traditional manual ways.
* cover painting is more sustainable, corrosion-resistant, uniform and smooth, using sand blasting powder painting process
3.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.
4.How about the delivery time?
A: Within 15-35 days after we confirm you requirement.
5.what kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
