Quick Details
-
Brand Name:
-
ONV
-
Model Number:
-
ONV-POE31064PF
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
10/100M PoE switch 6 port unmanaged
-
PoE Ports:
-
Port 1- 4
-
MAC Address:
-
1K
-
Jumbo frames:
-
9.6K
-
Max Power Per Port:
-
30W
-
Total PWR / Input Voltage:
-
65W (AC100-240V)
-
Operating temperature:
-
-20~+55°C
-
Dimensions:
-
118*95*28mm
-
Warranty:
-
3 Years
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
1.6Gbps
-
Brand Name:
-
ONV
-
Model Number:
-
ONV-POE31064PF
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
10/100M PoE switch 6 port unmanaged
-
PoE Ports:
-
Port 1- 4
-
MAC Address:
-
1K
-
Jumbo frames:
-
9.6K
-
Max Power Per Port:
-
30W
-
Total PWR / Input Voltage:
-
65W (AC100-240V)
-
Operating temperature:
-
-20~+55°C
-
Dimensions:
-
118*95*28mm
-
Warranty:
-
3 Years
OEM/ODM PoE switch 4 8 16 24 ports 10/100M & Gigabit unmanaged 48V ethernet fiber switch poe IEEE802.3af/at suitable for CCTV,NVR
This is a standard PoE switch, designed and developed independently by ONV to meet the needs of the network power supply. It adopts the latest high-speed Ethernet switching chip, ultra-high backplane bandwidth design, and has extremely fast data processing capabilities to improve smooth data transmission performance, With PoE ports and uplink RJ45 ports. Among them, all RJ45 ports support network cable power supply. it's suitable for Hikvision, Dahua and other brands with IEEE802.3af/at PoE powered devices(PD)
Software specification
Communication mode: Support half-duplex and full-duplex.
Exchange mode: store-and-forward
Rate of data signaling: Half-duplex mode
POE Standard: IEEE802.3af/at, each PoE port MAX 30W
Working Environment
Operating Temperature - 2 0℃ to +55 ℃
Storage Temperature -40℃ to +75 ℃
ORDERING INFORMATION
|
Model |
Port |
External Power Supply |
|
ONV-POE31064PF |
4*10/100M PoE ports and 2*155M uplink SFP ports |
65W |
|
ONV-POE31064PF-at |
110W |
|
|
ONV-POE31108PG |
8*10/100M PoE port and 2*10/100/1000M uplink RJ45 ports |
65W |
|
ONV-POE31108PG-at |
110W |
|
|
Related Product |
||
|
ONV-POE31064PL |
4*10/100M PoE ports and 2*10/100M uplink RJ45 ports |
65W |
|
ONV-POE31064PL -at |
110W |
|
|
ONV-POE31108PL |
8*10/100M PoE ports and 2*10/100M uplink RJ45 ports |
110W |
|
ONV-POE31108PL -at |
250W |
|
|
ONV-POE31004PLD |
4*10/100M PoE port and 1*10/100M uplink RJ45 port |
65W |
|
ONV-POE31004PLD -at |
110 |
|
|
ONV-POE31008PLD |
8*10/100M PoE port and 1*10/100M uplink RJ45 port |
110W |
|
ONV-POE3100 8 PLD -at |
250W |
|
|
ONV- POE31064PFG |
4*10/100M PoE port and 1*10/100/1000M uplink RJ45 port and 1*1000M uplink SFP slot port |
65W |
|
ONV- POE31064PFG -at |
110W |
|
|
ONV- POE31108PFG |
8*10/100M PoE port and 1*10/100/1000M uplink RJ45 port and 1*1000M uplink SFP slot port |
110W |
|
ONV- POE31108PFG -at |
250W |
|
|
Built-in Power Supply |
||
|
ONV-H1064PLD |
4*10/100M PoE ports and 2*10/100M RJ45 port |
65W |
|
ONV-H1108PLD |
8*10/100M PoE ports and 2*10/100M RJ45 port |
110W |
|
ONV-H1016PLD |
16*10/100M PoE ports and 2*10/100/1000M RJ45 port&1*1000M SFP port |
250W |
|
ONV-H10 24PLD |
24*10/100M PoE ports and 2*10/100/1000M RJ45 port&1*1000M SFP port |
|
Dimension
