Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty
-
Brand Name:
-
MAXIZM
-
Place of Origin:
-
China
-
Engine Brand:
-
Famous
-
Gear Box Brand:
-
Famous
-
Cargo Tank Dimension:
-
4000*3300*1600mm
-
Product name:
-
40 ton Mining Dump Truck
-
Engine:
-
OM502
-
Kerb Mass:
-
73000kg
-
Min Turning Clearance:
-
8865mm
-
Fuel:
-
550L
-
Wheelbase front-mid:
-
4450mm
-
Wheelbase mid-rear:
-
1940mm
-
Max Torque:
-
2300/1300Nm/rpm
-
Max speed:
-
60km/h
-
Cooling system:
-
240L
Quick Details
-
Condition:
-
New
-
Horsepower:
-
251 - 350hp
-
Emission Standard:
-
Euro 3
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
≥30T
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service, Shop warranty
-
Brand Name:
-
MAXIZM
-
Place of Origin:
-
China
-
Engine Brand:
-
Famous
-
Gear Box Brand:
-
Famous
-
Cargo Tank Dimension:
-
4000*3300*1600mm
-
Product name:
-
40 ton Mining Dump Truck
-
Engine:
-
OM502
-
Kerb Mass:
-
73000kg
-
Min Turning Clearance:
-
8865mm
-
Fuel:
-
550L
-
Wheelbase front-mid:
-
4450mm
-
Wheelbase mid-rear:
-
1940mm
-
Max Torque:
-
2300/1300Nm/rpm
-
Max speed:
-
60km/h
-
Cooling system:
-
240L
Products Description
XDA45: 1. all-terrain self-adaptive driving technology, the whole vehicle features high safety, high reliability and high
intelligence,has been exported overseas in bulk.
2. Imported OM502 engine, power reaches 350kW, 8-cylinder water-cooled, V-arranged, turbocharged intercooled, multi-point electronic injection diesel engine, powerful. It is sturdy and durable.
3. XDA45 also highlights low energy consumption, easy maintenance, and high driving comfort.
intelligence,has been exported overseas in bulk.
2. Imported OM502 engine, power reaches 350kW, 8-cylinder water-cooled, V-arranged, turbocharged intercooled, multi-point electronic injection diesel engine, powerful. It is sturdy and durable.
3. XDA45 also highlights low energy consumption, easy maintenance, and high driving comfort.
Product Paramenters
|
Item
|
|
|
Unit
|
Parameter
|
||
|
Dimension
|
Overall Length
|
|
mm
|
10690
|
||
|
|
Overall Width
|
|
mm
|
3370
|
||
|
|
Overall Height
|
|
mm
|
3793
|
||
|
|
Wheelbase front-mid
|
|
mm
|
4450
|
||
|
|
Wheelbase mid-rear
|
|
mm
|
1940
|
||
|
|
Tire center distance
|
Front
|
mm
|
2600
|
||
|
|
|
Mid & Rear
|
mm
|
2600
|
||
|
Weight
|
Total Weight
|
|
kg
|
73000
|
||
|
|
Payload
|
|
kg
|
39000
|
||
|
|
Curb Weight
|
|
kg
|
34000
|
||
|
Weight Distribution
|
Unload
|
Front
|
kg
|
17000 (50%)
|
||
|
|
|
Mid & Rear
|
kg
|
17000 (50%)
|
||
|
|
Loaded
|
Front
|
kg
|
21600 (29.6 %)
|
||
|
|
|
Mid & Rear
|
kg
|
51400 (70.4%)
|
||
|
Power Train
|
Engine
|
|
/
|
OM502
|
||
|
|
Rated Power
|
|
kW/HP/rpm
|
350/1800
|
||
|
|
Max Torque
|
|
Nm/rpm
|
2300/1300
|
||
|
|
Drive
|
|
/
|
6×6
|
||
|
|
Tires
|
|
/
|
29.5R25
|
||
|
Driving Performance
|
Max speed
|
|
km/h
|
60
|
||
|
|
Min Turning Clearance
|
|
mm
|
8865
|
||
|
|
Max Grade ability
|
|
%
|
45
|
||
|
|
Max Steering Angle
|
|
°
|
±45
|
||
|
|
Minimum Ground Clearance
|
|
mm
|
565
|
||
|
Working Parameter
|
Loading Height
|
|
mm
|
3180
|
||
|
|
Hoist Time
|
|
s
|
12
|
||
|
|
Hoist Angle
|
|
°
|
70
|
||
|
Service Capacities
|
Fuel
|
|
L
|
550
|
||
|
|
Hydraulic Oil
|
|
L
|
300
|
||
|
|
Engine Oil
|
|
L
|
60
|
||
|
|
Cooling system
|
|
L
|
240
|
||
|
|
Axles-Wheel Gear Oil (Each)
|
|
L
|
11.5
|
||
|
|
Axles-differential (Each)
|
|
L
|
33
|
||
|
Body
|
Struck
|
|
m3
|
17.5/18.5
|
||
|
|
2:1Heaped
|
|
m3
|
22.9/24
|
||
