Quick Details
-
Brand Name:
-
SUNS
-
Model Number:
-
SXP-206
-
Max. Current:
-
16A/4A
-
Operating Temperature:
-
-25~80℃
-
Protection Level:
-
IP40
-
weight:
-
about 12-14g
-
working temperature:
-
about -25~80
-
Certification:
-
International certification
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
125/250;24VDC
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SUNS
-
Model Number:
-
SXP-206
-
Max. Current:
-
16A/4A
-
Operating Temperature:
-
-25~80℃
-
Protection Level:
-
IP40
-
weight:
-
about 12-14g
-
working temperature:
-
about -25~80
-
Certification:
-
International certification
keyword :European safety standards mini micro switches SXP2
| Specification: | |
| Operating Speed: | 0.05mm-2m/sec |
| Operating Frequency | Mechanically:120ops/min |
| Electrically:30ops/min | |
| Insulation Resistance | >100MΩ@500V DC |
| Contact Resistance | <25mΩ |
| Electrical Rating | 3A/400VAC |
| Working Temperature | -25~+80°C |
| Dielectric Strength | same poles:1000V AC 50/60Hz 1min |
| pole to ground:2500V AC 50/60Hz 1min | |
| Service Life | Mechanically :1 millions |
| Electrically :1 millions | |
| Humidity | <85%RH |
| Weight | ~ 12g |
| Degree of Protection | IP40 |
| Operating force OF (Max) 5.88N | |
| Operating Characteristics: | |
| Release force RF (Min) 1N | |
| Pretravel PT (max) 3mm | |
| Differential Travel MD (Max) 2mm | |
| Total Travel TT (Min) 6mm | |
