Quick Details
-
Dimension(L*W*H):
-
750MM*540MM*1120MM
-
Power (kW):
-
7.5kw
-
Weight (KG):
-
470 KG
-
Product Name:
-
Pneumatic foam machine
-
Model:
-
CNMC-E3
-
Color:
-
Black, blue,Yellow
-
Power Source:
-
230V single phase,230V 3 phase,400V 3 phase,50/60HZ
-
Whole power:
-
7.5KW
-
Heater power:
-
3kw each side
-
Heating hose power:
-
1000w/15meters
-
Air source:
-
0.5-0.8MPa ≥ 0.9m³/min
-
Certification:
-
ce
-
Application:
-
Spray Wall
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HIGHTOP
-
Machine Type:
-
Pneumatic
-
Dimension(L*W*H):
-
750MM*540MM*1120MM
-
Power (kW):
-
7.5kw
-
Weight (KG):
-
470 KG
-
Product Name:
-
Pneumatic foam machine
-
Model:
-
CNMC-E3
-
Color:
-
Black, blue,Yellow
-
Power Source:
-
230V single phase,230V 3 phase,400V 3 phase,50/60HZ
-
Whole power:
-
7.5KW
-
Heater power:
-
3kw each side
-
Heating hose power:
-
1000w/15meters
-
Air source:
-
0.5-0.8MPa ≥ 0.9m³/min
-
Certification:
-
ce
-
Application:
-
Spray Wall
Product Description
Product advantages:
1. A voltmeter and ammeter are added, which can monitor the voltage and current inside the machine in real time.
2. Upgraded high-power cylinder, the spraying effect is stronger, and the atomization effect is better
3.The leakage protector is added to prevent machine leakage, damage to electrical components and human electric shock, and improve
safety performance
safety performance
4.Optimize the circuit layout, reduce fault points, and make it easier to troubleshoot
5.The appearance design is more beautiful and atmospheric, conforms to the principle of artificial mechanics, is easy to move and
operate, and adds handrail
operate, and adds handrail
6. The quick opening door is installed, which makes the maintenance more convenient.
Specification
|
Model
|
CNMC-E3
|
|
Power Source
|
230V single phase,230V 3 phase,400V 3 phase,50/60HZ
|
|
Whole power
|
7.5KW
|
|
Heater power
|
3kw each side
|
|
Heating hose power
|
1000w/15meters
|
|
Driven mode
|
Pneumatic
|
|
Air source
|
0.5-0.8MPa ≥ 0.9m³/min
|
|
Chemical output
|
2-12kg/min
|
|
Max. Output pressure
|
17Mpa
|
|
A and B chemical output ratio
|
1:1
|
|
Max hose support
|
90 meters
|
|
Machine size
|
800*700*1150mm
|
|
Machine weight
|
150kg
|
