Quick Details
-
Weight (KG):
-
3000
-
Type:
-
ZYDZS-800
-
Capacity:
-
500-1000Kg/h
-
Energy supply:
-
AC/3A/50HZ, 380 V or customerized
-
Raw material:
-
scrap PCB;TV, Cellphone, Computer Board and other print circuit board
-
Final Materials Size:
-
about 4-8cm
-
Machine Power:
-
45Kw
-
Certification:
-
CE ISO
-
Machine Weight:
-
3.5ton
-
Blade Materials:
-
As per your demands
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
SUNY
-
Power (kW):
-
38
-
Weight (KG):
-
3000
-
Type:
-
ZYDZS-800
-
Capacity:
-
500-1000Kg/h
-
Energy supply:
-
AC/3A/50HZ, 380 V or customerized
-
Raw material:
-
scrap PCB;TV, Cellphone, Computer Board and other print circuit board
-
Final Materials Size:
-
about 4-8cm
-
Machine Power:
-
45Kw
-
Certification:
-
CE ISO
-
Machine Weight:
-
3.5ton
-
Blade Materials:
-
As per your demands
PARAMETERS
|
Model
|
ZY-S600
|
ZY-S800
|
ZY-S1000
|
ZY-S1200
|
ZY-S1500
|
|
Motor Power (kw)
|
22
|
45
|
55
|
75
|
110
|
|
Rotor-knives (pcs)
|
26+4
|
36+6
|
48+6
|
58
|
98
|
|
Blade Material
|
Cr12MoV
SKDII
D2
|
Cr12MoV
SKDII
D2
|
Cr12MoV
SKDII
D2
|
Cr12MoV
SKDII
D2
|
Cr12MoV
SKDII
D2
|
|
Rotor Diameter (mm)
|
260
|
400
|
400
|
500
|
550
|
|
Rotor Speed (r/min)
|
75
|
75
|
75
|
80
|
80
|
|
Cutting Chamber (mm)
|
600x600
|
800x800
|
1000x1000
|
1200x1200
|
1500x1500
|
|
Hydraulic Power (kw)
|
2.2
|
3
|
4
|
5.5
|
7.5
|
|
Cylinder Stroke (mm)
|
600
|
800
|
1000
|
1200
|
1500
|
|
Machine Size (mm)
|
1800x1600x1850
|
2200x1780x2100
|
2500x1850x2300
|
3500x2000x2400
|
4800x2300x2400
|
|
Weight (kg)
|
2200
|
3700
|
4500
|
7000
|
9800
|
The above shredder is our standard configuration. For different raw materials to be shredded, the configuration might be different. Please feel free to contact us for detailed information or special request;
SUITABLE RAW MATERIALS
lt is mainly used for shredding and recycling various thick-wall waste materials and leftover materials in the plastic industry. lt can effectively shred and crush large materials ( such as extra-thick head materials, nozzle materials, gate materials, large plastic pipe fittings, large-diameter thick-wall PE pipes, PE head materials, plastic,packaging barrels, large bundles of plastic films, large bundles of woven bags, rolled,films, paper, fibers, plastic boxes, plastic garbage cans, TV casings, computer shells printer housings,copper wires, forklift pallets, plastic clamping plates, plastic turnover boxes, etc. ) and is suitable for crushing and recycling various materials of plastic rubber and wood. Shredded particles can be small to 20mm according to different needs.
ADVANTAGE
1.The main shaft is driven by gear reducer, running smoothly, with low noise and large torque. 2.The material of the knife: Cr12MoV (Japanese brand SKD-11, American brand D2); the moving knife uses the "y" or "one" word installation way to make the knife cut evenly. reduce energy consumption and reduce noise in the whole work; each knife has 4 cutting edges, and then rotates 90 degrees after wear; each set has 2 cutting edges. After wearing, it can be rotated for 180 degrees to continue to use: the blade on the rotor can be disassembled for easy cleaning, maintenance. 3. We can supply different rollers according to different material. Choosing the right rollers can improve machine performance and production efficiency. We can supply the following three rollers: High performance roller, hard material roller and film roller. 4. We have designed three different knives holders according to the material, such as welded knife holders, assembled knife holders and CNC cutting knife holders.
MAIN STRUCTURES
1.Shaft, moving blades, fixed blades, reducer, motors, feeding hopper, discharge port, electric control cabinet control panel, screen, roller, knives holder, ect. 2. After shreddering, the dimension of most large plastic or other material will reduce 30%, some material dimenison after shreddering can up to 50%. (We have arranged many videos. Please contact us freely if you need.)
The blade can be used in four directions Blade quality have 9CrSi, C12MoV, SKD-Il，D2 etc.Can be customized according to customer.
T
Hydraulic-driven pusher: The hydraulic-driven pusner is equipped with an adjustable guide block and adopts advanced sealing design.
Ash chute - remove the dust from the pusher in the shredding process so as to protect the hydraulic system
PLC Intelligent control system :
When the equipment is overloaded, the knife roller will turn and reverse
automatically, and the equipment will stop working automatically when there is no feeding materials.
