Item
|
Detail
|
Parameter
|
|
Vehicle
|
Model
|
CLW5039XLC6
|
|
|
Overall dimensions(L*W*H/mm)
|
5320*1695*2500
|
|
|
Upper box body size(L*W*H/mm)
|
2900*1380*1450
|
|
|
passenger allowed in cab
|
2 person
|
|
|
Gross weight(kgs)
|
3150
|
|
|
Curb weight(kgs)
|
2145
|
|
|
Traction system
|
4*2 left hand drive or right hand drive
|
|
|
wheel base(mm)
|
3050
|
|
|
Max speed(km/h)
|
120
|
|
Chassis
|
Brand
|
Foton automobile co,.ltd
|
|
|
Tire specification
|
195R15C
|
|
|
Tire no.
|
4+1(spare)
|
|
|
Transmission
|
manual
|
|
Engine
|
Model
|
4Q20M
|
|
|
manufacturer
|
Foton
|
|
|
fuel type
|
Gasoline
|
|
|
Horse Power(kw/hp)
|
95/130
|
|
|
Exhaust(ml)
|
1998
|
|
|
Emission standard
|
Euro 3/4/5
|
|
Body parameter
|
Dimension of panel
|
Length 0-18000mm, Width 0-3000mm, Height 0-3000mm
|
|
|
Standard thickness
|
Our standard thickiness is 80mm. But the thickness can be changed according to customer's requirements, like 60mm and 100mm
|
|
|
Body material
|
inside and outside:FRP/color steel panel/aluminium alloy/Stainless steel
middle: 80mm polyurethane foam/XPS |
|
|
Compartment structure
|
Don’t open at the top, rear door opening , with one side door, with stainless door frames and door accessory
|
|
|
Advantage
|
1)It is good at strength and long life
2)Non-corrosion, non-pollution, anti-brine, acid and soda-resisting 3)Easy to be assembled and repaired at site |
|
Refrigerated unit parameter
|
Refrigerator brand
|
Thermo king, origin USA
Carrier, origin USA HANA,origin China Kaixue, origin China Songhan,origin China, etc. |
|
|
Cooling temperature
|
+5 celsius~-18 celsius
|
