studio church fixed videowall mount portable display panel 500x500mm P1.95 P2.5 P2.6 P2.8 P2.97 digital rgb led sign indoor

1. The new structure design enables diversified installation to meet the hanging-up and stacking requirements, can be applied to achieve a variety of different occasions to meet various application requirements.
2. User-friendly design, more convenient installation, more efficient and secure; High strength, high toughness, and deformation; More reliable cabinet patchwork and cable connection,
3. Cabinets adopt rapid assembling sets, Which can be beautiful but also a real rapid disassembling.
4. Good thermal design. Taking structural heat emitting to keep the cabinet a excellent heat dissipation even no fan installation.
5. The entire cabinet with die casting aluminum alloy material is more lightweight and practical.
6. Compact base design, so that the whole screen space can be smaller a lot.
7. Higher IP rating; New system, High refresh rate, High brightness, True color output; Breathtaking gray level
8. Low. Has excellent heat dissipation design and performance. It is low noise and doesn't need external fan or air-condition. With the features of lightweight and low power consumption, it can reduce the labor cost of installation and operating cost.
9. The same size cabinet can be compatible with different specification displays of different DOT pixels. (P3.9, P4.81, P5.2, P6.25)

Technical Parameters:

Technical Prameters
PROJECT				P2.97 indoor LED screen display for rental
Pixel pitch				2.97m
Pixel density				112,896Pixels/sqm
Module size(W*H)				250 W(mm)		250 H(mm)
Module pixels(W*H)				84Pixels(W)		84Pixels(H)
Pixel configuration				1Red 1Green 1Blue
Drive mode				constant current driving 1/22 scan
LED lamp type				Black SMD3528
Cabinet size(W*H*D)				500 W(mm)		500 H(mm)
Cabinet resolution				168Pixels(W)		168Pixels(H)
Color scale				65,536 degree
View angle(H/V)				140/120 degree
Brightness (White balance)				≥1200cd/sqm.
Power consumption(one cabinet)				Max:800W/sqm.     Average:450W/sqm.
Operating Voltage				AC100V±10% or 220V ±10%;   50---60HZ
Net weight				9Kg/Cabinet
Operating temperature				-20°C----+50°C (Customized power supply:-45°C---+60°C)
Operating humidity				10%_95%RH
Life time				≥100,000hours
MTBF				5,000 hours
Whole Display Flatness				≤0.1mm Juncture
Frame frequency				>60 Hz/s
Refresh rate				≥1000Hz /s
Control distance				100m (without repeater), single mode fiber:20km, multi mode fiber: 500m
Power				110V/220V±15% 50--60Hz
LED control system				LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable
Operating system				Windows 2000 / Windows Xp / Windows 7
Protections for outdoor display				IP31
Maintenance way				Rear  Access or Front Access
Accepting signal with video processor				PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
