Quick Details
-
Theoretical Shot Volume(cm³):
-
250 cm³
-
Injection Rate (g/s):
-
45 g/s
-
Injection Weight (g):
-
264 g
-
Screw Speed (rpm):
-
30 - 60 rpm
-
Screw diameter (mm):
-
25 mm
-
Weight (KG):
-
2000 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
300 mm
-
Brand Name:
-
Jinyu TUA
-
Power (kW):
-
16.8 kW
-
Theoretical Injection Volume:
-
73cm3
-
Max.Injection Pressure:
-
450Mpa(kgf/cm2)
-
Injection Rate:
-
45cm3/sec
-
Injection Speed:
-
50mm/s
-
Clamping Force:
-
617/(63)kN(tf)
-
System Pressure:
-
13.7(140)Mpa(kgf/cm2)
-
Oil Tank Capacity:
-
35L
-
Electric Power:
-
AC380V5.5KW
-
Machine Dimension:
-
1500*1850*1750mm
-
Machine Weight:
-
2000kg
Quick Details
-
Mold Height(mm):
-
10 - 20 mm
-
Ejector Stroke(mm):
-
250 mm
-
Ejector Force(kN):
-
617 kN
-
Theoretical Shot Volume(cm³):
-
250 cm³
-
Injection Rate (g/s):
-
45 g/s
-
Injection Weight (g):
-
264 g
-
Screw Speed (rpm):
-
30 - 60 rpm
-
Screw diameter (mm):
-
25 mm
-
Weight (KG):
-
2000 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
300 mm
-
Brand Name:
-
Jinyu TUA
-
Power (kW):
-
16.8 kW
-
Theoretical Injection Volume:
-
73cm3
-
Max.Injection Pressure:
-
450Mpa(kgf/cm2)
-
Injection Rate:
-
45cm3/sec
-
Injection Speed:
-
50mm/s
-
Clamping Force:
-
617/(63)kN(tf)
-
System Pressure:
-
13.7(140)Mpa(kgf/cm2)
-
Oil Tank Capacity:
-
35L
-
Electric Power:
-
AC380V5.5KW
-
Machine Dimension:
-
1500*1850*1750mm
-
Machine Weight:
-
2000kg
Product Description
Specification
|
item
|
value
|
|
Applicable Industries
|
Garment Shops, Manufacturing Plant, Home Use, Retail, Printing Shops, Other, Silicone production industry
|
|
Core Components
|
Motor, Pump, PLC, Other, Engine
|
|
Theoretical Injection Volume
|
73cm3
|
|
Max.Injection Pressure
|
450Mpa(kgf/cm2)
|
|
Injection Rate
|
45cm3/sec
|
|
Injection Speed
|
50mm/s
|
|
Clamping Force
|
617/(63)kN(tf)
|
|
System Pressure
|
13.7(140)Mpa(kgf/cm2)
|
|
Oil Tank Capacity
|
35L
|
|
Electric Power
|
AC380V5.5KW
|
|
Machine Dimension
|
1500*1850*1750mm
|
|
Machine Weight
|
2000kg
|
Packing & Delivery
Seaworthy wooden case
