- Product Details
- {{item.text}}
Quick Details
-
Design Printing:
-
Offer Printing
-
Material:
-
washi paper
-
Feature:
-
Waterproof
-
Use:
-
MASKING
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
QJC
-
Model Number:
-
s-19
-
Color:
-
black or white or as your require
-
Product name:
-
butyl insulating self-adhesive tape
-
Application:
-
waterproof insulating
-
Width:
-
19mm, 25mm, 38mm black or white or as your require
-
Thickness:
-
0.5mm, 0.76mm black or white or as your require
-
Length:
-
5m, 9.1m, 10m black or white or as your require
-
Printing:
-
Offered Printing
-
Sample:
-
Freely
-
Temperature resistance:
-
100degree
Quick Details
-
Adhesive:
-
Rubber
-
Adhesive Side:
-
Double Sided
-
Adhesive Type:
-
Pressure Sensitive, Water Activated
-
Design Printing:
-
Offer Printing
-
Material:
-
washi paper
-
Feature:
-
Waterproof
-
Use:
-
MASKING
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
QJC
-
Model Number:
-
s-19
-
Color:
-
black or white or as your require
-
Product name:
-
butyl insulating self-adhesive tape
-
Application:
-
waterproof insulating
-
Width:
-
19mm, 25mm, 38mm black or white or as your require
-
Thickness:
-
0.5mm, 0.76mm black or white or as your require
-
Length:
-
5m, 9.1m, 10m black or white or as your require
-
Printing:
-
Offered Printing
-
Sample:
-
Freely
-
Temperature resistance:
-
100degree
Product Description
Specifications
butyl rubber double sided tape
Stretch and wrap self-fusing rubber tape for a moisture-tight, insulating seal on electrical connections. High resistance to salt water, steam and oil. To use, remove 2" to 3" of tape from the roll, remove the liner, stretch tape to twice the supplied width and wrap it spirally around the object with a 50% overlap. In minutes the tape will react with itself to provide protection from moisture, most chemicals, and provide insulation to 490V per mil. Since the tape does not use mastic or adhesive it can be removed easily without leaving any residue. Also useful for emergency pipe & hose repairs and wrapping tool handles. 1" x 16.4' roll. (0.8mm x 25mm x 5m).
1. Excellent physical and electrical properties with a high degree of stability under conditions of use.
2. self-adhesive rubber insulating tape high voltage insulation tape amalgamates rapidly when applied under
tension to provide a void-free homogeneous wrapping without the need for external heat or pressure.
3. Compatible with a wide range of rubber and plastic dielectric cable insulation. These include polyethylene, cross-link
ed polyethylene, ethylene propylene rubber, PVC, butyl and neoprene.
4. Excellent resistance to water and ozone.
5. The tape will remove cleanly when cut, allowing it to be used as temporary insulation or protection.
6. Service temperature -40 to +100°C.
butyl rubber double sided tape
Stretch and wrap self-fusing rubber tape for a moisture-tight, insulating seal on electrical connections. High resistance to salt water, steam and oil. To use, remove 2" to 3" of tape from the roll, remove the liner, stretch tape to twice the supplied width and wrap it spirally around the object with a 50% overlap. In minutes the tape will react with itself to provide protection from moisture, most chemicals, and provide insulation to 490V per mil. Since the tape does not use mastic or adhesive it can be removed easily without leaving any residue. Also useful for emergency pipe & hose repairs and wrapping tool handles. 1" x 16.4' roll. (0.8mm x 25mm x 5m).
1. Excellent physical and electrical properties with a high degree of stability under conditions of use.
2. self-adhesive rubber insulating tape high voltage insulation tape amalgamates rapidly when applied under
tension to provide a void-free homogeneous wrapping without the need for external heat or pressure.
3. Compatible with a wide range of rubber and plastic dielectric cable insulation. These include polyethylene, cross-link
ed polyethylene, ethylene propylene rubber, PVC, butyl and neoprene.
4. Excellent resistance to water and ozone.
5. The tape will remove cleanly when cut, allowing it to be used as temporary insulation or protection.
6. Service temperature -40 to +100°C.
Specification
|
Feature
|
Waterproof
|
|
Use
|
MASKING
|
|
Color
|
black or white or as your require
|
|
Product name
|
butyl insulating self-adhesive tape
|
|
Application
|
waterproof insulating
|
|
Width
|
19mm, 25mm, 38mm black or white or as your require
|
|
Thickness
|
0.5mm, 0.76mm black or white or as your require
|
|
Length
|
5m, 9.1m, 10m black or white or as your require
|
|
Printing
|
Offered Printing
|
|
Material
|
PTFE
|
|
Sample
|
Freely
|
|
Temperature resistance
|
100degree
|
Usage
This tape is designed for insulation wire and cable termination and joints with the phase to phase voltage up to 10kv and the conductor continuous operating temperature peached 90 degree emergency overload temperature reached 90 degree and short circuit temperature to 70 degree and also for other purpose of insulation and waterproof seal.
