Quick Details
-
Application:
-
landscaping, tourist attractions, park squares,etc
-
Color Rendering Index(Ra):
-
85
-
Lamp Luminous Flux(lm):
-
300
-
CRI (Ra>):
-
85
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
customized
-
Model Number:
-
EL-F281
-
Material:
-
304 stainless steel + PC
-
Light Color:
-
3000/4500K
-
Solar panel size:
-
172*193mm
-
Light size:
-
32*23mm
-
Connecting line:
-
one for one main line 2.5M+6M (each light is 1M line)
-
Power supply:
-
Solar Panel
-
Battery:
-
lithium battery 18650*1
-
Charging time:
-
4-6hours
-
Working time:
-
16hours
-
Certification:
-
ce rohs
Quick Details
-
Color Temperature(CCT):
-
3000/4500K
-
Warranty(Year):
-
1-Year
-
Lamp Body Material:
-
Stainless steel
-
Application:
-
landscaping, tourist attractions, park squares,etc
-
Color Rendering Index(Ra):
-
85
-
Lamp Luminous Flux(lm):
-
300
-
CRI (Ra>):
-
85
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
customized
-
Model Number:
-
EL-F281
-
Material:
-
304 stainless steel + PC
-
Light Color:
-
3000/4500K
-
Solar panel size:
-
172*193mm
-
Light size:
-
32*23mm
-
Connecting line:
-
one for one main line 2.5M+6M (each light is 1M line)
-
Power supply:
-
Solar Panel
-
Battery:
-
lithium battery 18650*1
-
Charging time:
-
4-6hours
-
Working time:
-
16hours
-
Certification:
-
ce rohs
Specification
|
Color Temperature(CCT)
|
3000/4500K
|
|
Lamp Body Material
|
Stainless Steel
|
|
IP Rating
|
IP67
|
|
Model Number
|
EL-F281
|
|
Application
|
landscaping, tourist attractions, park squares,etc
|
|
Material
|
304 stainless steel + PC
|
|
Light Color
|
3000/4500K
|
|
Solar panel size
|
172*193mm
|
|
Light size
|
32*23mm
|
|
Connecting line
|
one for one main line 2.5M+6M (each light is 1M line)
|
|
Power supply
|
Solar Panel
|
|
Battery
|
lithium battery 18650*1
|
|
Charging time
|
4-6hours
|
|
Working time
|
16hours
|
Application place:
It is widely used for decorative lighting in landscaping, tourist attractions, park squares, garden villas, courtyard corridors,lawns, eaves and other places.
Product features:
● No need to connect to mains, no wiring, low voltage safety, photovoltaic new energy green lighting
2. Output open circuit voltage: 6V
3. Output maximum short-circuit current: 430mA
4. Output power 2.6W
5. Charging time: 4-6H under normal light
● Lithium battery parameters:
1. Battery specification: lithium battery 18650*1
2.Nominal voltage/capacity: 3.7V 2200mAH
3. Cell internal resistance: less than 60MΩ
4. Overcharge protection voltage: 4.25V+0.05V
5. Over discharge protection voltage: 2.5V
6. Protection release voltage: 3.0V
● LED splint lamp parameters:
1. Rated voltage: 3.2V
2. Rated current: 60-180mA
3. Rated power: 0.2W*6
4. Color temperature: 3000K/4000K
5. Illumination: 17000LUX/each lamp at 180MA current, 5500LUX/each lamp at 60MA current
6. Working hours: 16H
How to use:
1. Install the ground plug or fix the bracket with screws, install the solar panel in an unobstructed place, and adjust the solar panel to a 45-degree direction to let direct sunlight.
2. Use ground plugs or fixed brackets to install the lamps in the relevant places that need to be used.
3. Toggle the "ON" switch on the control box to turn on the power, and it will enter the charging and discharging state.
4. The solar panel has a light control function, which is automatically charged during the day and lights up automatically at
night.
Pay attention to things:
1. This product has a protection level of IP65, please do not install it in low-lying water areas, and it is strictly prohibited to use it underwater.
3. It is recommended to charge the product in time when it is left for more than 3 months, the effect will be better.
4. The ground plug of this product is a sharp object, please don't play with children, please install it firmly.
It is widely used for decorative lighting in landscaping, tourist attractions, park squares, garden villas, courtyard corridors,lawns, eaves and other places.
Product features:
● No need to connect to mains, no wiring, low voltage safety, photovoltaic new energy green lighting
● It adopts 6 plywood lamp combinations and is equipped with embedded parts, which can be used flexibly
● Adopt imported chip high-brightness LED lamp beads, which has the effect of side lighting decoration
● Built-in 3.7V/2200mA lithium battery, 6 lights are on at the same time, working time up to 16H
The brightness is divided into two sections, the first 6H, the output current is 180MA/H, the rear 6H, the output current is
60MA/H
● Use high-efficiency solar panels with light control function for charging during the day and lighting at night, intelligent
control
● Internal use of overvoltage and overcurrent imported IC control protection, safety guarantee
● Solar panels are equipped with ground plugs and brackets, which can be installed in garden villas and square green spaces at will
● Practical and novel, private model patented product s
Product parameters :
● Appearance size and material:
1. Solar panel: material ABS size 172*193mm
2. Splint lamp: material 304 stainless steel + PC size Ø32*23mm
3. Connecting line: waterproof, one for one main line 2.5M+6M (each light is 1M line)
● Solar panel parameters:
1. Polysilicon/Laminated
60MA/H
● Use high-efficiency solar panels with light control function for charging during the day and lighting at night, intelligent
control
● Internal use of overvoltage and overcurrent imported IC control protection, safety guarantee
● Solar panels are equipped with ground plugs and brackets, which can be installed in garden villas and square green spaces at will
● Practical and novel, private model patented product s
Product parameters :
● Appearance size and material:
1. Solar panel: material ABS size 172*193mm
2. Splint lamp: material 304 stainless steel + PC size Ø32*23mm
3. Connecting line: waterproof, one for one main line 2.5M+6M (each light is 1M line)
● Solar panel parameters:
1. Polysilicon/Laminated
2. Output open circuit voltage: 6V
3. Output maximum short-circuit current: 430mA
4. Output power 2.6W
5. Charging time: 4-6H under normal light
● Lithium battery parameters:
1. Battery specification: lithium battery 18650*1
2.Nominal voltage/capacity: 3.7V 2200mAH
3. Cell internal resistance: less than 60MΩ
4. Overcharge protection voltage: 4.25V+0.05V
5. Over discharge protection voltage: 2.5V
6. Protection release voltage: 3.0V
● LED splint lamp parameters:
1. Rated voltage: 3.2V
2. Rated current: 60-180mA
3. Rated power: 0.2W*6
4. Color temperature: 3000K/4000K
5. Illumination: 17000LUX/each lamp at 180MA current, 5500LUX/each lamp at 60MA current
6. Working hours: 16H
How to use:
1. Install the ground plug or fix the bracket with screws, install the solar panel in an unobstructed place, and adjust the solar panel to a 45-degree direction to let direct sunlight.
2. Use ground plugs or fixed brackets to install the lamps in the relevant places that need to be used.
3. Toggle the "ON" switch on the control box to turn on the power, and it will enter the charging and discharging state.
4. The solar panel has a light control function, which is automatically charged during the day and lights up automatically at
night.
Pay attention to things:
1. This product has a protection level of IP65, please do not install it in low-lying water areas, and it is strictly prohibited to use it underwater.
2. This product has a built-in battery and has a discharge protection function. If you do not use it for a long time, please put the solar panel in the sun to charge it before it can work normally.
3. It is recommended to charge the product in time when it is left for more than 3 months, the effect will be better.
4. The ground plug of this product is a sharp object, please don't play with children, please install it firmly.
Product Description
Packing & Delivery
Packing list:
1. Solar panel*1
2 lights*6
3. Screw *2
4. Plastic expansion plug*2
5. Ground plug *1
6. Manual *1
1. Solar panel*1
2 lights*6
3. Screw *2
4. Plastic expansion plug*2
5. Ground plug *1
6. Manual *1
Box Packing
6pcs/box
carton size: 43.5*39.5*38.5cm , 24boxes/carton,19.5kg
8pcs/box
carton size: 43.5*39.5*38.5cm, 24boxes/carton, 20kg
