Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
China
-
Model Number:
-
BLN-006TB1
-
Function:
-
Heating Cooling hot water
-
Compressor:
-
Full DC Inverter Compressor
-
Keyword:
-
Monoblock
-
working ambient temperature:
-
-30℃-45℃
-
Controller:
-
Wifi Controller
-
Refrigerant type:
-
R32
Quick Details
-
Warranty:
-
5 years
-
Application:
-
Household, Hotel
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
China
-
Model Number:
-
BLN-006TB1
-
Function:
-
Heating Cooling hot water
-
Compressor:
-
Full DC Inverter Compressor
-
Keyword:
-
Monoblock
-
working ambient temperature:
-
-30℃-45℃
-
Controller:
-
Wifi Controller
-
Refrigerant type:
-
R32
Products Description
Features:
○
Energy class: A+++
○
Heating+Cooling+DHW
○
Full DC inverter Panasonic compressor and fan motor
○
-30℃ inverter EVI
○
WIFI smart control
○
R32 refrigerant, environmental friendly
○
Outlet water temperature up to 60℃
Reducing and preventng global warming an important mission of Power World R32 used in has GWP of only one third comparing to R410A. Besides. 30% amount of refrigerant less needed for R32 heat pump systems than R410A ones.
According to different needs of users, we have developed a variety of operating modes: users can choose different operating frequency modes according to actual needs, which helps users save a lot of electricity bills.
Full DC Frequency Conversion Technology, with a Pleasant "0" Fluctuation
The heat pump adopts full DC frequency conversion technology to lock in a comfortable temperature range. It can adjust the operating temperature range in real time and adjust the operating power in real time. At the same time, it can achieve soft wind in summer and constant temperature and comfort in winter.
Stable operation of jet enthalpy enhancement technology at -35°C
Innovative use of the international leading level of jet enthalpy enhancement technology, the technology adopts the internationally renowned ultra-low temperature compressor, jet enthalpy enhancement technology, the use of a compressor, to achieve quasi-two-stage compression, -35 °C extremely cold weather can also operate normally.
The dual-rotor compressor operates steadily with 3D stereo noise reduction. It can run quietly like a library, allowing us to enjoy a quiet home environment.
Ten layers of security protection for peace of mind
From refrigerant, water flow to power supply, set up a ten-item all-round safety protection system, all-time and all-round escort, so that the equipment can operate more safely and stably.
Product Paramenters
|
Model
|
|
|
BLN-006TB1
|
|
|
Power supply
|
|
V/Ph/Hz
|
220~240/1/50
|
|
|
Nominal Heating (Max)
(A7/6℃,W30/35℃) |
Heating Capacity
|
KW
|
6.46(2.50-8.30
|
|
|
|
Heating Capacity
|
KW
|
1.31
|
|
|
|
COP
|
W/W
|
4.93
|
|
|
Nominal Heating (Max)
(A7/6℃,W30/35℃) |
Heating Capacity
|
KW
|
5.92
|
|
|
|
Heating Capacity
|
KW
|
1.85
|
|
|
|
COP
|
W/W
|
3.21
|
|
|
Nominal Cooling (Max)
(A35/24℃,W12/7℃) |
Cooling Capacity
|
KW
|
5.66
|
|
|
|
Power Input
|
KW
|
1.74
|
|
|
|
EER
|
W/W
|
3.25
|
|
|
ERP Level（Outlet water temp. at 35℃）
|
|
/
|
A+++
|
|
|
ERP Level（Outlet water temp. at 55℃）
|
|
/
|
A++
|
|
|
Rated input power
|
|
kW
|
2.71
|
|
|
Rated input current
|
|
A
|
12
|
|
|
Refrigerant/Weight
|
|
/
|
R32
|
|
|
Rated water flow
|
|
m3/h
|
1.1
|
|
|
Fan quantity
|
|
/
|
1
|
|
|
Fan motor type
|
|
/
|
DC inverter
|
|
|
Compressor
|
|
/
|
Panasonic / DC inverter / Rotary / EVI
|
|
|
Circulating pump
|
|
/
|
Inverter type / Built-in
|
|
|
IP Class
|
|
/
|
IPX4
|
|
|
Sound pressure at 1m distance
|
|
dB(A)
|
50
|
|
|
Max outlet water temperature
|
|
℃
|
60
|
|
|
Water piping connections
|
|
/
|
DN 25 (1")
|
|
|
Pressure drop at rating water flow
|
|
kPa
|
25
|
|
|
Operating temperature range( Heating mode)
|
|
℃
|
-30~45
|
|
|
Operating temperature range( Cooing mode)
|
|
℃
|
16~45
|
|
|
Unpacked Dimensions(LxDxH)
|
|
mnm
|
1110*445*850
|
|
|
Packed Dimensions (LxDxH)
|
|
mnm
|
1160*530*1010
|
|
|
UnPacked Weight
|
|
kg
|
95
|
|
|
Packed Weight
|
|
kg
|
105
|
|
