Quick Details
-
Radio Type::
-
Transceiver
-
Product name:
-
PIR20
-
Modulation:
-
GFSK
-
Baud rate:
-
10K bps
-
Bandwidth:
-
93.79KHz
-
Battery:
-
1.5V
Quick Details
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
JOY
-
Model Number:
-
PIR20
-
Radio Type::
-
Transceiver
-
Product name:
-
PIR20
-
Modulation:
-
GFSK
-
Baud rate:
-
10K bps
-
Bandwidth:
-
93.79KHz
-
Battery:
-
1.5V
Technology Specification:
- The Latest ARM Core CPU Technology;
- Sub-1G RF Band: ISM 433/868/915MHz,Universe;
- GFSK, Transceiver, Two-way Message;
- Wireless Transmit Power: Max +12dBm;
- Wireless Receiver Sensitivity: -116dBm;
- Wireless Cover Range: ≤400 meters
- Motion Detect Distance: 5-10 meters
- Standby Current: ≤ 4uA
- Operation Current: ≤ 21mA
- Battery Status Report Scale: 1% (1-100%)
- Battery Size: 2x 1.5 V AA ;
- Low Power Consumption: Yes, support 3 years battery-life
- Storage Temperature: -40ºC - 85ºC;
- Operation Temperature: -30ºC - 75ºC;
- Dimension: 58.5*108*43mm;
- Mounting Mode: wall mounting via screw or double-side attach stick tape;
- Application Environment: Indoor;
For occasions:
house, convenience store, car, hospital school, library, bank, financial office, office, let, community, factory floor, storehouse of factory, parking lot
