Quick Details
-
Warranty:
-
30 years
-
Brand Name:
-
Jinko
-
Model Number:
-
JAM72D40 MB 565-590
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278±2mmx1134±2mmx30±1mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
-
OEM Order:
-
Acceptable
-
Flash Report:
-
Available
-
Custom Carton Mark:
-
Available
-
Weight:
-
31.8KG each panel
-
MOQ:
-
1 pallet
-
Packing:
-
36 pcs/ pallet
-
Load:
-
720 pcs/ 1X40'HQ
-
OEM:
-
Acceptable OEM Service
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, N-TYPE
-
Panel Efficiency:
-
22.8%
-
Warranty:
-
30 years
-
Brand Name:
-
Jinko
-
Model Number:
-
JAM72D40 MB 565-590
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2278±2mmx1134±2mmx30±1mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
-
OEM Order:
-
Acceptable
-
Flash Report:
-
Available
-
Custom Carton Mark:
-
Available
-
Weight:
-
31.8KG each panel
-
MOQ:
-
1 pallet
-
Packing:
-
36 pcs/ pallet
-
Load:
-
720 pcs/ 1X40'HQ
-
OEM:
-
Acceptable OEM Service
Product Description
Specification
|
Module Type
|
JAM72D40-565/MB
|
JAM72D40-570/MB
|
JAM72D40-575/MB
|
JAM72D40-580/MB
|
JAM72D40-585/MB
|
JAM72D40-590/MB
|
|||||
|
Rated Maximum Power(Pmax)[W]
|
565
|
570
|
575
|
580
|
585
|
590
|
|||||
|
Open Circuit Voltage(Voc)[V]
|
51.30
|
51.52
|
51.73
|
51.95
|
52.16
|
52.37
|
|||||
|
Maximum Power Voltage(Vmp)[V]
|
43.42
|
43.62
|
43.82
|
44.02
|
44.22
|
44.43
|
|||||
|
Short Circuit Current(Isc)[A]
|
13.69
|
13.74
|
13.79
|
13.84
|
13.89
|
13.94
|
|||||
|
Maximum Power Current(Imp)[A]
|
13.01
|
13.07
|
13.12
|
13.17
|
13.23
|
13.28
|
|||||
|
Module Efficiency
[%]
|
21.9
|
22.1
|
22.3
|
22.5
|
22.6
|
22.8
|
|||||
|
Power Tolerance
|
0~+5w
|
|
|
|
|
|
|||||
|
Temperature Coefficient of lsc(a_lsc)
|
+0.046%/°C
|
|
|
|
|
|
|||||
|
Temperature Coefficient of Voc(β_Voc)
|
-0.260%/°C
|
|
|
|
|
|
|||||
|
Temperature Coefficient of Pmax(v_Pmp)
|
- 0.300%/°C
|
|
|
|
|
|
|||||
|
STC
|
Irradiance 1000W/m²,cell temperature 25C,AM1.5G
|
|
|
|
|
|
|||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
