Quick Details
-
Product name:
-
All in one Home energy storage battery
-
Model:
-
HJ-03/HJ-04/HJ-05
-
Application:
-
Home Energy Storage System
-
Nominal energy:
-
3kw,4kw,5kw
-
Surge Power:
-
6kw,8kw,10kw
-
Rated voltage:
-
51.2V/(100*N)Ah
-
MPPT working voltage:
-
60~130VDC
-
Output efficiency:
-
90%
-
Certificate:
-
UN38.3,FCC,UL1973,CE,IEC62619
-
Battery life:
-
6000 cycles
-
Plug Type:
-
Standard
Quick Details
-
Model Number:
-
HJ-03/HJ-04/HJ-05
-
Brand Name:
-
HJ
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
All in one Home energy storage battery
-
Model:
-
HJ-03/HJ-04/HJ-05
-
Application:
-
Home Energy Storage System
-
Nominal energy:
-
3kw,4kw,5kw
-
Surge Power:
-
6kw,8kw,10kw
-
Rated voltage:
-
51.2V/(100*N)Ah
-
MPPT working voltage:
-
60~130VDC
-
Output efficiency:
-
90%
-
Certificate:
-
UN38.3,FCC,UL1973,CE,IEC62619
-
Battery life:
-
6000 cycles
-
Plug Type:
-
Standard
Products Description
Huijue all in one series brings storage solutions to customers with safe performance and first-class quality.
|
Model
|
HJ-03
|
HJ-04
|
HJ-05
|
||
|
Rated Output Power
|
3KW
|
4KW
|
5KW
|
||
|
Surge Power
|
6KW
|
8kW
|
10KW
|
||
|
Storage energy
|
5.12KWhxN
|
|
|
||
|
Battery voltage and capacity
|
51.2V/(100xN)Ah
|
|
|
||
|
Output voltage
|
230Vac土5%
|
|
|
||
|
Output efficiency
|
0.9
|
|
|
||
|
AC output voltage
|
230Vac
|
|
|
||
|
Frequency Range
|
50Hz/60Hz (Automatic detection)
|
|
|
||
|
Maximum PV OCV
|
145VDC
|
|
|
||
|
MPPT working voltage
|
60~130VDC
|
|
|
||
|
Maximum PV charging current
|
80A
|
|
|
||
|
Maximum AC charging current
|
60A
|
|
|
||
|
Charging temperature
|
0~55°C
|
|
|
||
|
Discharging temperature
|
subzero 10~55°C
|
|
|
||
|
Storage temperature
|
subzero 15~60°C
|
|
|
||
|
Relative humidity
|
5%-95%
|
|
|
||
|
Battery module voltage and capacity
|
51.2V100Ah
|
|
|
||
|
Battery module weight
|
55Kg
|
|
|
||
|
Battery module size
|
600x505x230mm
|
|
|
||
|
Inverter weight
|
20Kg
|
|
|
||
|
Inverter size
|
600x505x150mm
|
|
|
||
|
Bottom bracket weight
|
10Kg
|
|
|
||
|
Bottom bracket size
|
600x505x109mm
|
|
|
||
Certification
