Quick Details
-
Brand Name:
-
DAWANG
-
Voltage:
-
220V/380V
-
Blade No.s:
-
5
-
Available Fan Diameter::
-
26ft, 24ft, 22ft, 20ft, 18ft, 16ft, 14ft, 12ft, 10ft, 9ft, 8ft
-
Application:
-
Air Cooling & Ventilation
-
Package::
-
Wooden case
-
Certification:
-
CE, RoHS, FCC
-
Coverage Area::
-
1500 Spuare Meter
Quick Details
-
Mounting:
-
Ceiling Fan
-
Power:
-
1.5kw, 1.1kw, 0.75kw
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
DAWANG
-
Voltage:
-
220V/380V
-
Blade No.s:
-
5
-
Available Fan Diameter::
-
26ft, 24ft, 22ft, 20ft, 18ft, 16ft, 14ft, 12ft, 10ft, 9ft, 8ft
-
Application:
-
Air Cooling & Ventilation
-
Package::
-
Wooden case
-
Certification:
-
CE, RoHS, FCC
-
Coverage Area::
-
1500 Spuare Meter
|
Product Series
|
W.Fans Series
|
|
|
|
|
|
|
|
|
||||||||
|
Model
|
W26
|
W24
|
W22
|
W20
|
W18
|
W16
|
W14
|
W12
|
WS10
|
||||||||
|
Specification/ Diameter(m)
|
8
|
7.3
|
6.7
|
6.1
|
5.5
|
4.9
|
4.2
|
3.6
|
3.1
|
||||||||
|
Speed (rpm)
|
10-45
|
10-55
|
10-60
|
10-60
|
10-70
|
10-75
|
10-80
|
10-90
|
10-100
|
||||||||
|
Full-load air volume(m³/min)
|
17676
|
16130
|
14804
|
13800
|
12152
|
10826
|
9280
|
7954
|
6849
|
||||||||
|
Coverage area(m²)
|
2462
|
2123
|
1809
|
1520
|
1256
|
1017
|
804
|
615
|
452
|
||||||||
|
Rated power rate(kw)
|
1.5
|
|
|
1.1
|
|
|
0.75
|
0.4
|
|
||||||||
|
Average consumption(kwh)
|
≤1.2
|
≤1.0
|
|
≤0.7
|
0.75
|
|
0.55
|
≤0.4
|
|
||||||||
|
Noise(dB)
|
≤38
|
|
|
|
|
|
|
|
|
||||||||
|
Power supply (V)
|
380V/220S
|
|
|
|
|
|
|
|
|
||||||||
|
Full-load current(A)
|
2.8（380V）/4.6（220V）
|
|
|
2.6（380V）/3.0（220V）
|
|
|
2.5
|
2.0
|
|
||||||||
|
Weight(kg)
|
106
|
101
|
99
|
96
|
95
|
90
|
88
|
86
|
82
|
||||||||
