Quick Details
-
Model Number:
-
FOC-4000L
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
330*150*73MM
-
Weight:
-
5KGS
-
Inverter type:
-
4000 watt pure sine wave inverter
-
Over temperature Protection:
-
Yes
-
Low Voltage Protection:
-
Yes
-
Peak Power:
-
4000W
-
Rated Power:
-
2000W
-
Efficiency:
-
88%
-
Over Voltage Protection:
-
ion: Yes
-
OEM:
-
Accept OEM Logo
Quick Details
-
Output Current:
-
13.6A
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Foclink
-
Model Number:
-
FOC-4000L
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
330*150*73MM
-
Weight:
-
5KGS
-
Inverter type:
-
4000 watt pure sine wave inverter
-
Over temperature Protection:
-
Yes
-
Low Voltage Protection:
-
Yes
-
Peak Power:
-
4000W
-
Rated Power:
-
2000W
-
Efficiency:
-
88%
-
Over Voltage Protection:
-
ion: Yes
-
OEM:
-
Accept OEM Logo
Product Description
2000W(Peak 4000W) Power Inverter Pure Sine Wave DC 12V to AC 110V 120V Converter Back up Power Supply for RV, Home, Car Use, Solar
System
Introduction of power inverter:
System
* REALLY POWERFUL INVERTER:This inverter provides 3000W(Max 6000W) of continuous DC to AC power through an AC power outlet.
High-end manufacturing processes make it the ultimate car travel charger for road trips, vacations or remote work locations.
* ✔ VERSATILE:Equipped with AC power socket, this DC to AC inverter will safely power your TV, DVD player, air cushion pump, or
laptop, game console, camera, PSP, kindle, GPS, camping lamps, etc. to ensure you stay connected with the world while
traveling.
* ✔ MULTIPLE PROTECTION:External fuses are added for safe use, full protection and automatic shutdown, which can ensure your
equipment and car from overheating, overload, low load, short circuit, low voltage and overvoltage.
* ✔ EASY TO USE:The power inverter comes with a battery clip Connection line for your convenience. The durable structure and
high-quality materials can withstand harsh environments and can be used throughout the season, making it ideal for use in cars,
boats, campsites, or anywhere that requires AC power.
* ✔ QUALITY ASSURANCE:If you find any problems with our products, please contact us immediately by email and we will help you
solve the problem within 24 hours.If you need more styles, please search our store name (LNLN), our store has a variety of
styles and colors, you can go to we store to view.
Feature & advantage:
1. Efficiency: 85%-92%
2. The service life can reach a decade
3. Working noise is low and the efficiency is high
4. Strong ability of resist concussion
5. Good load ability: Inductive , capacitive load and Hybrid load
6. Protection: Battery Low Alarm/Battery Shut down/Over Voltage/Over Temp/ Output Short/Overload
Specification
Model
|
FOC-600L
|
FOC-1000L
|
FOC-1500L
|
FOC-2000L
|
FOC-3000L
|
FOC-4000L
|
FOC-5000L
|
|||||||
Display
|
LCD Display
|
|
|
|
|
|
|
|||||||
DC Input
|
|
|
|
|
|
|
|
|||||||
Rate voltage
|
12Vdc/24Vdc/48Vdc/60Vdc/72Vdc
|
|
|
|
|
|
|
|||||||
Range voltage
|
10-15Vdc/20-30Vdc/40-60Vdc/50-75Vdc/60-90Vdc
|
|
|
|
|
|
|
|||||||
Output
|
|
|
|
|
|
|
|
|||||||
Output Voltage
|
110Vac or 220Vac±5%
|
|
|
|
|
|
|
|||||||
Output Frequency
|
50Hz or 60Hz±0.1%
|
|
|
|
|
|
|
|||||||
Wave
|
Pure Sine wave
|
|
|
|
|
|
|
|||||||
Output Power
|
600W
|
1000W
|
1500W
|
2000W
|
3000W
|
4000W
|
5000W
|
|||||||
Peak Power
|
1000W
|
2000W
|
3000W
|
4000W
|
6000W
|
8000W
|
10000W
|
|||||||
Conversion Efficiency
|
≥90%
|
|
|
|
|
|
|
|||||||
Protect function
|
|
|
|
|
|
|
|
|||||||
Function-1
|
Input reverse connection protection: Fuse
|
|
|
|
|
|
|
|||||||
Function-2
|
Input low voltage protection : 20Vdc±0.3V
|
|
|
|
|
|
|
|||||||
Function-3
|
Recovery voltage : 24V(25.5V±0.3)
|
|
|
|
|
|
|
|||||||
Function-4
|
Input high voltage protection: 30Vdc±0.3V
|
|
|
|
|
|
|
|||||||
Function-5
|
Over temperature protect: 80°±5°
|
|
|
|
|
|
|
|||||||
No-load current
|
0.3A
|
0.6A
|
0.7A
|
0.7A
|
1.0A
|
1.0A
|
1.0A
|
|||||||
Over load protection
|
660±50W
|
1100±50W
|
1650±50W
|
2200±50W
|
3300±50W
|
4000±50W
|
5000±50W
|
|||||||
Total Harmonic Distortion
|
≤3%
|
|
|
|
|
|
|
|||||||
Working temperature
|
-5~+50℃
|
|
|
|
|
|
|
|||||||
Storage temperature
|
-20~+70℃
|
|
|
|
|
|
|
|||||||
Cooling method
|
Intelligent temperature controlled air cooling
|
|
|
|
|
|
|
|||||||
Mechanical properties
|
|
|
|
|
|
|
|
|||||||
Input terminal
|
Terminal form
|
|
|
|
|
|
|
|||||||
Output socket
|
According request
|
|
|
|
|
|
|
|||||||
Housing material
|
Aluminum
|
|
|
|
|
|
|
|||||||
Size(mm)
|
220*105*60
|
290*120*70
|
290*150*73
|
330*150*73
|
380*220*93
|
480*220*100
|
580*285*19
|
|||||||
Weight (kg)
|
1.3
|
2
|
2.5
|
3
|
6
|
8
|
10.5
|
