- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Hongjin
-
Model Number:
-
HJ-HW
-
Product name:
-
Constant temperature and humidity environmental test chamber
-
Humidity range:
-
5%~98%
-
Temperature range:
-
-70°C-150°C
-
Power supply:
-
220V/380V
-
Keyword:
-
environmental temperature humidity climatic test chamber
-
Type:
-
low temperature test chamber
-
Certificate:
-
CE ISO FCC
-
MOQ:
-
1PCS
-
Color:
-
Customer Required
Quick Details
-
Warranty:
-
12 MONTHS, 12 Months
-
Power:
-
Electronic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hongjin
-
Model Number:
-
HJ-HW
-
Product name:
-
Constant temperature and humidity environmental test chamber
-
Humidity range:
-
5%~98%
-
Temperature range:
-
-70°C-150°C
-
Power supply:
-
220V/380V
-
Keyword:
-
environmental temperature humidity climatic test chamber
-
Type:
-
low temperature test chamber
-
Certificate:
-
CE ISO FCC
-
MOQ:
-
1PCS
-
Color:
-
Customer Required
specification
Product Description .
Hongjin Three-Cavity Environment Climatic Test Chamber Artificial Controlled Temperature Humidity Test Chiamber For Rubber
Temperature and Humidity Test Chamber is used to test the performance of materials in various environments and test the heat resistance, cold resistance, dry resistance and humidity resistance of various materials. Suitable for testing the quality of products such as electronics, electrical appliances, mobile phones, communications, meters, vehicles, plastic products, metals,food, chemicals, building materials, medical care, aerospace, etc.
Product Paramenters
|
Model number
|
TH-80 （A~F）
|
TH-150 (A~F)
|
TH-225 (A~F)
|
TH-408 (A~F)
|
TH-800 (A~F)
|
TH-1000 (A~F)
|
|||||
|
Internal Size W x H x D(cm)
|
40 x50 x 40
|
50 x 60 x 50
|
60 x 75 x 50
|
80 x 85 x 60
|
100 x 100 x 80
|
100 x 100 x 100
|
|||||
|
External Size W x H x D(cm)
|
120×165×115
|
130x170x125
|
140x185x130
|
165x195x155
|
185x200x175
|
190x210x185
|
|||||
|
Temperature range
|
Low temperature: A: + 25 ° CB: 0 ° C, C: - 20 ° C, and D (150 ° C) : to 40 ° C, E: 60 ° C, F: high temperature - 70 °, 100℃
|
|
|
|
|
|
|||||
|
Humidity range
|
20%-98% R. H.(10%-98% R. H) : (5%-98% R. H is the special selection condition)
|
|
|
|
|
|
|||||
|
Analytical accuracy of temperature and humidity/distribution accuracy
|
0.1°C 0.1% R.H./±2.0 °C ±3.0% R.H.
|
|
|
|
|
|
|||||
|
Temperature and humidity control accuracy
|
±0.5°C, ±2.5%R.H.
|
|
|
|
|
|
|||||
|
Heating/cooling time
|
The temperature rises about 4.0℃/ min; Cooling is about 1.0℃/ min
|
|
|
|
|
|
|||||
|
Internal and external material
|
The inner and outer boxes are made of SUS304# stainless steel plate (optional baking paint).
|
|
|
|
|
|
|||||
|
Insulation material
|
High temperature resistant high density chloroethylene formate foam insulator material
|
|
|
|
|
|
|||||
|
Cooling system
|
Air-cooled/single-stage compressor (-20°C); Two-stage compressor (-40° C-70 °C)
|
|
|
|
|
|
|||||
|
Safety protection device
|
No fuse switch, compressor overload protection, refrigerant high and low pressure protection, over humidity and over temperature protection, fuse, fault warning system, water shortage alarm protection
|
|
|
|
|
|
|||||
|
accessories
|
Operating hole built-in glass door (optional), recorder (optional), viewing window, 50mm test hole, PL box light, partition, wet and dry ball gauze, casters, horizontal tripod
|
|
|
|
|
|
|||||
|
Power supply
|
AC220V 50/60Hz & AC380V 50/60Hz3
|
|
|
|
|
|
|||||
|
Weight (approximate)
|
150KG
|
180KG
|
250KG
|
350KG
|
500KG
|
520KG
|
|||||
