Quick Details
-
EINECS No.:
-
231-072-3
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
jinhua
-
Model Number:
-
2120AB-1
-
Type:
-
liquid
-
Color:
-
Clear
-
Certificate:
-
ROHS,REACH, PAHS, ASTM, EN-71
-
Mixing Ratio:
-
A:B = 2:1
-
Shelf life:
-
6 Months
-
Lead Time:
-
3days
-
Product name:
-
Epoxy AB Glue
-
Keywords:
-
UV resistant epoxy resin
-
Appearance:
-
Top clear liquid
Quick Details
-
CAS No.:
-
38891-59-7
-
Other Names:
-
Composite Material epoxy resin
-
MF:
-
C15H16O2C2H7ONC3H5OCl
-
EINECS No.:
-
231-072-3
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
jinhua
-
Model Number:
-
2120AB-1
-
Type:
-
liquid
-
Color:
-
Clear
-
Certificate:
-
ROHS,REACH, PAHS, ASTM, EN-71
-
Mixing Ratio:
-
A:B = 2:1
-
Shelf life:
-
6 Months
-
Lead Time:
-
3days
-
Product name:
-
Epoxy AB Glue
-
Keywords:
-
UV resistant epoxy resin
-
Appearance:
-
Top clear liquid
1.JINHUA clear and transparent epoxy resin AB glue made from basic pure resin and do well in adhesive.
2.Good at UV and yellow resistance,self leveling,without bubble,high brightness.
3.Can be cured at nomal temperature or by heating.
4.Clear,low viscosity,nature defoaming, super transprency and good performance after mixed.
5.Can get any color you want by add pigments.
6.Easy to clean and repair.
7.No ripple,bright in surface,odourless,eco-friendly,nontoxic,waterproof and so on.
Certificated
Application
2120AB-1 can be widely used for surfboard coating, carbon fiber products coating, snowboard coating, lamp potting and mold filling, etc..
The effect of surfboard
2120AB-1 Laminating Epoxy Resin and Hardener System is a high quality resin which can be used for a wide range of applications, from fiber-reinforced composites to thin film epoxy coatings,such as fiberglass, carbon fiber, kevlar, or many other types of composite reinforcement. The syrup-like consistency will generate fast wet-out and easy application of any reinforcement.This Epoxy Resin System is 2:1,a low viscosity, clear, low odor epoxy that is not only ideal for layup use, but also as a sealer of porous substrates, such as wood. Because of its penetrating power, it is also excellent for boat repair and general marine repair.
Properties before Hardening
Part |
2120A-1 |
2120B-1 |
Color |
Light Blue |
Transparent |
Specific gravity |
1.15 |
0.96 |
Viscosity (25℃) |
6000-10000CPS |
250MAXCPS |
Mixing ratio |
A: B = 100:50(weight ratio) |
|
Hardening conditions |
25 ℃×2H to 4H or 55℃×1.5H (2 g) |
|
Usable time |
25℃×15min (100g) |
Operation
1.Weigh A and B glue according to the given weight ratio into the prepared cleaned container, fully mixed the mixture again the container wall by clockwise, place it along for 3 to 5 minutes, and then it can be used.
2.Take the glue according to the usable time and dosage of mixture to avoid wasting. When the temperature is below 15 ℃, please heat A glue to 30 ℃ first and then mix it to the B glue (A glue will be thicken in low temperature ); The glue must be sealed lid after use to avoid rejection caused by moisture absorption.
3.When the relative humidity is higher than 85%, the surface of the cured mixture will absorb moisture in the air, and form a layer of white mist in the surface, so when the relative humidity is higher than 85%, is not suitable for room temperature curing, suggest to use the heat curing.
Properties after Hardening
Hardness, shore D |
<90 |
Withstand voltage, KV/mm |
22 |
Flexural strength, Kg/mm2 |
25 |
Volume resistivity, Ohm3 |
1x10 15 |
Surface resistance, Ohmm2 |
5X10 15 |
Thermal conductivity, W/M.K |
0.59 |
Induced electric loss, 1KHZ |
0.42 |
Withstand high temperature, ℃ |
140 |
Moisture absorption, % |
<0.15 |
Compressive strength, Kg/ mm2 |
11.4 |
Caution
1,The operating environment should be ventilate and should keep away from fire. Closely sealed after use.
2, Avoid eye contact, in case of contact, wash with plenty of water and get medical attention immediately.
3, If contact skin, wrap with clean cloth or paper, and wash it with water and soap.
4, Keep away from children.
5, Please take a trial before application to avoid usage mistake.
Storage And Shelf Life
1, Store at the temperature of 25°C or cool and dry place. Avoid from sunlight, high temperature or high humidity environment.
2, Use up as soon as possible when opened. It is strictly forbidden to expose to the air for a long time after it is opened to avoid affecting the quality of the products. The shelf life is six months in the room temperature of 25°C.
FREE SAMPLE IS AVAILABLE!!!
Jinhua professional produce and market all kinds of epoxy resin AB glue which covers a very large range of applications: Soft AB glue for stickers, LED strip potting, badge, nameplate, nail cutters, keychain!!!
Hard clear resin for LED channel letters, photo frame coating, hand made diamond, jewelry, crafts, nacklace, bangles, bracklets, earrings, rings, miniatures such as simulated water, soup,lquid drinks and fishbows to be used in a child's dollhouse, anything you can image clear and shinning, but cheap and easy to operate!!!
Coating resin for surfboard, paddle, christmas ball, globe, foam products coating, bicycles, boats, golf clubs,skies, snowboards, swimming pool, garage, wood table coating, Epoxy flooring, to make it hard and durable!!!
Special ahhesion for wood, metal, glass, stone and some plastic.With very strong and high durable bond after cured!!!
Flexible potting resin for electronic products such as motors, generators, transformers, swithgeear, insulators, mold filling,LEDs, perfectly to protect the potting items from short circuit, dust, water, and moisture, and giving the potting items a more stable and longer life than unpotted products!!!
Pls contact us to discuss your application for a best EPOXY SOLUTION!!!
All of our products has ROHS, REACH, PAHS, ASTM, EN-71 CERTIFICATE!!!
