Quick Details
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
Macy
-
Model Number:
-
AA-1800F
-
Focal Length:
-
200nm
-
Wavelength Range:
-
190nm-900nm
-
Spectral Bandwidth:
-
0.1,0.2,0.4,,1.0,2.0nm (automatic adjustable)
-
Light Source:
-
≤3 lamps automatic turret, automatic alignment
-
Power Supply:
-
110/220V (+5% ~ -10%), 60/50Hz; 5000VA
-
Grating:
-
1800/mm
-
Wavelength Accuracy:
-
≤0.15nm
-
Wavelength Repeatability:
-
±0.1nm
-
Baseline Stability:
-
≤±0.002A/30 minutes( static) ≤±0.005A/30 minutes.(dynamic)
-
Power:
-
double cathode power built-in high performance lamps
-
Environment temperature:
-
+15℃~+35℃
-
Relative humidity:
-
20~80%
Quick Details
-
Warranty:
-
1 years
-
Size:
-
1260*640*710mm
-
Weight:
-
120KG
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
Macy
-
Model Number:
-
AA-1800F
-
Focal Length:
-
200nm
-
Wavelength Range:
-
190nm-900nm
-
Spectral Bandwidth:
-
0.1,0.2,0.4,,1.0,2.0nm (automatic adjustable)
-
Light Source:
-
≤3 lamps automatic turret, automatic alignment
-
Power Supply:
-
110/220V (+5% ~ -10%), 60/50Hz; 5000VA
-
Grating:
-
1800/mm
-
Wavelength Accuracy:
-
≤0.15nm
-
Wavelength Repeatability:
-
±0.1nm
-
Baseline Stability:
-
≤±0.002A/30 minutes( static) ≤±0.005A/30 minutes.(dynamic)
-
Power:
-
double cathode power built-in high performance lamps
-
Environment temperature:
-
+15℃~+35℃
-
Relative humidity:
-
20~80%
Specification
|
Wavelength Range
|
190nm-900nm
|
|
|
Light Source
|
≤3 lamps automatic turret, automatic alignment
|
|
|
Power Supply
|
110/220V (+5% ~ -10%), 60/50Hz; 5000VA
|
|
|
Environment temperature
|
+15℃～+35℃
|
|
|
Relative humidity
|
20~80%
|
|
|
Wavelength Accuracy
|
≤0.15nm
|
|
|
Wavelength Repeatability
|
±0.1nm
|
|
|
Spectral Bandwidth
|
0.1、0.2、0.4,、1.0、2.0nm (automatic adjustable)
|
|
|
Baseline Stability
|
≤±0.002A/30 minutes( static) ≤±0.005A/30 minutes.(dynamic)
|
|
|
Grating
|
1800/mm
|
|
|
Flame atomizer
|
|
|
|
Characteristic concentration (Cu)
|
0.015ug/mL/1%
|
|
|
Detection limits (Cu)
|
0.002ug/mL
|
|
|
Precision
|
RSD≤0.5%
|
|
|
Combustion head
|
metal titanium combustion head
|
|
|
Atomizer
|
efficient glass atomizer
|
|
|
Atomizing chamber
|
explosion proof corrosion resistant material spray chamber
|
|
|
Control system
|
automatic PC control three light brick, automatic alignment, automatic optimization and automatic ignition
|
|
|
Safety protection
|
with automatic safety protection function,anti temperingautomatic gas path protection,acetylene gas leak-age alarm, automatic
shutdown system, abnormal automatic power-off |
|
|
Background correction:
|
deuterium background correction:correction of the 1A background
|
|
|
Data processing
|
|
|
|
Measurement methods
|
flame method,hydride method
|
|
|
Concentration calculation method
|
standard curve method(1～3 times curve),automatic matching,the standard addition method
|
|
|
Repetition survey frequency
|
1-99 times, calculating the average value, standard deviation and relative standard deviations are given
|
|
|
Results print
|
parameters print, data and graphics print,you can also export WORD,EXCEL document
|
|
|
Simple and convenient operation,lamp positionrotating, automatic ignition through software operating
|
|
|
|
Communication interface
|
computer and USB interface communication
|
|
AA-1800EL original suction automatic sampler method compass type
AS-1000 Automatic Sampler - ICP Product Common 1
AS-1000 automatic sampler-ICP product general 2
Product Description
Details Images
Standard accessories
Hydride generation
Air compressor
The power adapter
Gas control flowmeter
Element lamp
Combustion head
Combustion head
Atomizer
