Quick Details
-
Range of Spindle Speed(r.p.m):
-
2 - 62 r.p.m
-
Max. Turned Length (mm):
-
3150 mm
-
Spindle Motor Power(kW):
-
55
-
Place of Origin:
-
China
-
Brand Name:
-
Haisen
-
Model Number:
-
C5231
-
Weight (KG):
-
40000 KG
-
Max height of work piece:
-
2000 mm
-
Max weight of work piece:
-
10 t
-
Workbench diameter:
-
2830 mm
-
Max torque of Worktable:
-
63 KN.M
-
Max cutting force of tool post:
-
35 KN
-
Size of tool shank section:
-
30*40 mm
-
Square ram size:
-
240*240 mm
-
Beam travel:
-
1700 mm
-
Beam movement speed:
-
410 mm
-
Beam lifting motor power:
-
11 Kw
Quick Details
-
Max. Length of Workpiece (mm):
-
2000
-
Machining Capacity:
-
Heavy Duty
-
Spindle Bore(mm):
-
None
-
Range of Spindle Speed(r.p.m):
-
2 - 62 r.p.m
-
Max. Turned Length (mm):
-
3150 mm
-
Spindle Motor Power(kW):
-
55
-
Place of Origin:
-
China
-
Brand Name:
-
Haisen
-
Model Number:
-
C5231
-
Weight (KG):
-
40000 KG
-
Max height of work piece:
-
2000 mm
-
Max weight of work piece:
-
10 t
-
Workbench diameter:
-
2830 mm
-
Max torque of Worktable:
-
63 KN.M
-
Max cutting force of tool post:
-
35 KN
-
Size of tool shank section:
-
30*40 mm
-
Square ram size:
-
240*240 mm
-
Beam travel:
-
1700 mm
-
Beam movement speed:
-
410 mm
-
Beam lifting motor power:
-
11 Kw
|
Main Parameters
|
Unit
|
C5225
|
C5231
|
C5240
|
C5250
|
C5263
|
C5280
|
|||||
|
Processing control
|
/
|
Manual(DRO)
|
|
|
|
|
|
|||||
|
Max turning diameter
|
mm
|
2500
|
3150
|
4000
|
5000
|
6300
|
8000
|
|||||
|
Max height of work piece
|
mm
|
1600
|
2000
|
2500
|
3150
|
3500
|
4000
|
|||||
|
Max weight of work piece
|
t
|
10
|
10
|
32
|
50
|
120
|
150
|
|||||
|
Worktable diameter
|
mm
|
2250
|
2830
|
3200
|
4500
|
5700
|
7100
|
|||||
|
Main motor power
|
KW
|
55
|
55
|
55
|
75
|
90
|
125
|
|||||
|
Max torque of table
|
KN·m
|
63
|
63
|
65
|
150
|
250
|
250
|
|||||
