Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Growatt
-
Model Number:
-
SPF3500-5000ES
-
Input Voltage:
-
48V
-
Output Voltage:
-
230V
-
Output Current:
-
80A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
485*330*135MM
-
Certificate:
-
CE
-
Warranty:
-
2YEARS
-
Weight:
-
15KG
-
Battery voltage:
-
48VDC
-
RATED POWER:
-
5000VA/ 5000W
-
Parallel Capability:
-
Yes, 6 units
-
Surge Power:
-
10000VA
-
Maximum PV Array Power:
-
5500W
-
MPPT Range @ Operating Voltage:
-
120VDC ~ 430VDC
-
Maximum Efficiency:
-
97%
-
Charge Current:
-
80A
-
Operating Temperature:
-
0°C - 55°C
-
Storage Temperature:
-
-15°C - 60°C
Quick Details
-
Output Type:
-
Single, Three Phase
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
97%
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Growatt
-
Model Number:
-
SPF3500-5000ES
-
Input Voltage:
-
48V
-
Output Voltage:
-
230V
-
Output Current:
-
80A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
485*330*135MM
-
Certificate:
-
CE
-
Warranty:
-
2YEARS
-
Weight:
-
15KG
-
Battery voltage:
-
48VDC
-
RATED POWER:
-
5000VA/ 5000W
-
Parallel Capability:
-
Yes, 6 units
-
Surge Power:
-
10000VA
-
Maximum PV Array Power:
-
5500W
-
MPPT Range @ Operating Voltage:
-
120VDC ~ 430VDC
-
Maximum Efficiency:
-
97%
-
Charge Current:
-
80A
-
Operating Temperature:
-
0°C - 55°C
-
Storage Temperature:
-
-15°C - 60°C
Configuration List
|
Datasheet
|
SPF5000ES
|
|
|
Battery voltage
|
48VDC
|
|
|
INVERTER OUTPUT
|
|
|
|
RATED POWER
|
5000VA/ 5000W
|
|
|
Parallel Capability
|
Yes, 6 units
|
|
|
AC Voltage Regulation (Battery Mode)
|
230VAC ± 5% @ 50/60Hz
|
|
|
Surge Power
|
10000VA
|
|
|
Efficiency (Peak)
|
93%
|
|
|
Waveform
|
Pure sine wave
|
|
|
Transfer Time
|
10 ms (For Personal Computers); 20 ms (For Home Appliances)
|
|
|
|
|
|
|
SOLAR CHARGER
|
|
|
|
Maximum PV Array Power
|
5500W
|
|
|
MPPT Range @ Operating Voltage
|
120VDC ~ 430VDC
|
|
|
Maximum PV Array Open Circuit Voltage
|
450VDC
|
|
|
Maximum Solar Charge Current
|
100A
|
|
|
Maximum Efficiency
|
97%
|
|
|
AC CHARGER
|
|
|
|
Charge Current
|
80A
|
|
|
AC Input Voltage
|
230 VAC
|
|
|
Selectable Voltage Range
|
170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
|
|
|
|
|
|
|
PHYSICAL
|
|
|
|
Dimension (D/W/H) in mm
|
485/330/135
|
|
|
Net Weight (kgs)
|
12
|
|
|
OPERATING ENVIRONMENT
|
|
|
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|
|
Operating Temperature
|
0°C - 55°C
|
|
|
Storage Temperature
|
-15°C - 60°C
|
|
