BOTA welding table welding fixture table rotary table

BOTA welding table welding fixture table rotary table

FOB Reference Price: Get Latest Price

≥1 Sets

US $2300

≥5 Sets

US $2200

≥10 Sets

US $1800

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Voltage:: 220V/380V/440V/customize

Dimensions:: 5T TO 200T

Use:: seam longitudinal welding

Product name:: BOTA welding table welding fixture table rotary table

Application:: Wind Tower Fabrication

Function:: Welding Steel Tube

Name:: MIG Welding Machine

Keyword:: Welding Robot China

Welding Material:: Mild Steel

Color:: Blue

Welding Method:: TIG MIG PAW

Welding Speed:: 100-1000mm/min

Quick Details

Place of Origin:: Henan, China

Brand Name:: Bota

Weight (KG):: 750

Voltage:: 220V/380V/440V/customize

Dimensions:: 5T TO 200T

Use:: seam longitudinal welding

Product name:: BOTA welding table welding fixture table rotary table

Application:: Wind Tower Fabrication

Function:: Welding Steel Tube

Name:: MIG Welding Machine

Keyword:: Welding Robot China

Welding Material:: Mild Steel

Color:: Blue

Welding Method:: TIG MIG PAW

Welding Speed:: 100-1000mm/min

Product Overview

BOTA welding table welding fixture table rotary table

Bota turning rolls are used to accurately rotate a part about a weld head to produce high quality welds in a variety of different applications and to rotate parts for fit-up applications and pre/post heating processes. Welding is performed using TIG, MIG or SAW.

Bota have two standard models of turning rolls:

* Conventional adjustable type
* Self-Aligning type

FEATURES AT A GLANCE

* Mainly used for fit-up welding
* Roller distance could be changed by hydraulic cylinders to meet requirement of work pieces with different Diameter
* Work piece could be moved up & down, left & right
* Polyurethane wheels are much more durable
* Frequency speed control is applied for the adjustment of roller speed
* Loading capacity: from 1T- 200 Ton
* Roller speed: 65 mm/min to 1500 mm/min

Right elevation

Left elevation

Front elevation

PRODUCT SPECIFICATIONS

Model	Load (T)	Wheel Diameter (mm)	Wheel Width (mm)	Workpiece Diameter (mm)
BKT-5T	5	260	120	200-2000
BKT-10T	10	310	120	200-2500
BKT-20T	20	310	170	300-3000
BKT-30T	30	310	220	300-3500
BKT-40T	40	425	220	300-4000
BKT-50T	50	425	220	400-5000
BKT-60T	60	425	220	600-5000
BKT-80T	80	425	240	800-5500
BKT-100T	100	550	240	100-6000
BKT-150T	150	550	240	1100-7000
BKT-200T	200	600	260	1200-7800
