Quick Details
-
Battery Energy(kWh):
-
≤30kWh
-
Total Horsepower(Ps):
-
200-250Ps
-
Drive Motor:
-
Single
-
Model Number:
-
TK2600
-
Place of Origin:
-
Shandong, China
-
Battery Warranty:
-
10 months
-
Dimension:
-
4500*1400*1700mm
-
Number of Seats:
-
2
-
Tire Size:
-
R12
-
Airbags:
-
0
-
Size:
-
4500*1400*1700mm
-
Product Name:
-
truck electric
-
Carriage size:
-
2600*1400*350mm
-
Max speed:
-
45km/h
-
Min steering radius:
-
≤5m
-
Max climbing ability(full):
-
20%
-
Braking Distance:
-
≤7m
-
Working Range:
-
80-100km
-
Motor:
-
72V 4KW AC Motor, 3-5KW 6 Phase Permanent Magnet motor is optional
-
Braking Method:
-
Front Disc Rear Drum
Quick Details
-
Brand Name:
-
KEYU
-
Battery Type:
-
Lithium
-
NEDC Max. Range:
-
301 ~400 km
-
Battery Energy(kWh):
-
≤30kWh
-
Total Horsepower(Ps):
-
200-250Ps
-
Drive Motor:
-
Single
-
Model Number:
-
TK2600
-
Place of Origin:
-
Shandong, China
-
Battery Warranty:
-
10 months
-
Dimension:
-
4500*1400*1700mm
-
Number of Seats:
-
2
-
Tire Size:
-
R12
-
Airbags:
-
0
-
Size:
-
4500*1400*1700mm
-
Product Name:
-
truck electric
-
Carriage size:
-
2600*1400*350mm
-
Max speed:
-
45km/h
-
Min steering radius:
-
≤5m
-
Max climbing ability(full):
-
20%
-
Braking Distance:
-
≤7m
-
Working Range:
-
80-100km
-
Motor:
-
72V 4KW AC Motor, 3-5KW 6 Phase Permanent Magnet motor is optional
-
Braking Method:
-
Front Disc Rear Drum
Products Description
|
D
A
T
A
|
Items
|
TK2600
|
|
|
Size
|
4500*1400*1700mm
|
|
|
Carriage size
|
2600*1400*350mm
|
|
|
Max speed
|
45km/h
|
|
|
Min steering radius
|
≤5m
|
|
|
Max climbing ability（full）
|
20%
|
|
|
Braking Distance
|
≤7m
|
|
|
Working Range
|
80-200m
|
|
|
Motor
|
72V 4KW AC Motor, 3-5KW 6 Phase Permanent Magnet motor is optional
|
|
|
Min Ground Clearance
|
≥160mm
|
|
|
Loading Capacity（kg）
|
800-1200kg
|
|
|
Tread
|
2680mm
|
|
|
Wheel base
|
1200/1250mm
|
|
E
L
E
C
T
|
Battery
|
72V lead acid battery or lithium battery
|
|
L
|
Charger
|
Build-in smart car charger
|
|
E
|
Controller
|
Imported in-power controller
|
|
C
|
Driven Method
|
RR
|
|
T
|
Braking Method
|
Front Disc Rear Drum
|
|
|
Body Structure
|
Intelligent loading body
|
|
P
O
W
E
R
|
Front Axle loading Cap.
|
800kg
|
|
|
Rear axle loading capacity
|
1200kg
|
|
|
Climbing Ability
|
20-30%
|
|
|
Tyre
|
155/70R12 Pneumatic tyres
|
|
|
Steering system
|
Gear chain
|
|
|
Lights and signal
|
LED front lamp, turning light, rear lights, braking light,horn
|
|
|
Seat
|
leather+PU
|
|
|
instrument
|
Instrument panel,RDP button
|
