Quick Details
-
Application:
-
Mall
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Newelement
-
Model Number:
-
Cherrypan
-
Type:
-
Ceiling Tiles
-
Asbestos:
-
100% Asbestos free
-
Thickness:
-
6,8,9,12,15mm
-
Width & Length:
-
1220*2440,3050mm
-
Density:
-
≥1.2g/cm3
-
Usage:
-
Moisture proof Partition or Ceiling in dry or wet area
-
Fire rate time:
-
1 hour
-
Color:
-
White
-
Certification:
-
CE ISO BS
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
Others
-
Application:
-
Mall
-
Design Style:
-
Modern
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Newelement
-
Model Number:
-
Cherrypan
-
Type:
-
Ceiling Tiles
-
Asbestos:
-
100% Asbestos free
-
Thickness:
-
6,8,9,12,15mm
-
Width & Length:
-
1220*2440,3050mm
-
Density:
-
≥1.2g/cm3
-
Usage:
-
Moisture proof Partition or Ceiling in dry or wet area
-
Fire rate time:
-
1 hour
-
Color:
-
White
-
Certification:
-
CE ISO BS
Noise-Absorbing Mdf Waterproof Bathroom Wall Covering Panels
Product Feature
1.Durability with medium density
2.Outstanding sound insulation
3.Low moisture movement, immune to permanent water damage
4.Non combustible, no toxic gasses
5.Resistant to fungus, bacteria, insects, vermin, etc.
6.Good at anti-impact
7. Easy installation and maintenance
1.Specification
| Thickness | Width | Length |
| 6,8,9,12,15mm | 1220mm | 2440,3050mm |
|
REMARK: We can also supply other specification as the client’s specially requirement |
||
2.Physical properties
The following data are the average tested figures during manufacturing
| Item | Index | Unit | |||
| Density | ≥1.20 | g/cm3 | |||
| Thermal Conductivity | ≤0.29 | W/(m·k) | |||
| Water Absorption | ≤40 | % | |||
| Water Contain | ≤10 | % | |||
| Moisture Movement | ≤0.25 | % | |||
| Non-combustibility | GB 8624 Class A1,BS 476 part 4 | / | |||
| Bending Strength | Oven dry | Cross | ≥12.0 | Mpa | |
| Parallel | ≥9.0 | Mpa | |||
| REMARK: Please contact our technical department if you need more technical index. | |||||
3.Safety Capability
| Item | Index | Spection |
| Asbestos Including | 100% asbestos free | safe for application |
| Radioactive | <1.0 IRa | safe for application |
| <1.0 Ir | safe for application | |
| noncombustibility | A | the highest grade |
The purpose of Cherrypan is for indoor partition and ceiling of moisture proof and fire proof in the
wet area building for both civil and industrial application. It can be used as the base board and ceiling
in school ,shopping center, theater because of its high anti-impact property.It can be used in the building
for the high demand in private requirement and sound insulation
