Quick Details
-
Max. Loading Capacity:
-
600
-
Weight (KG):
-
690 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Farefly
-
Voltage:
-
22v/380v/440v customered
-
Power (kW):
-
11 kW
-
Product name:
-
FSY11
-
Name:
-
HIGH-SHEARING EMULSIFIER
-
Advantage:
-
Easy Operation High Efficiency
-
Certification:
-
CE ISO
-
Function:
-
Emulsifier Homogenizer
Quick Details
-
Barrel Volume (L):
-
600
-
Max. Loading Volume (L):
-
600 L
-
Range of Spindle Speed(r.p.m):
-
1 - 2900 r.p.m
-
Max. Loading Capacity:
-
600
-
Weight (KG):
-
690 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Farefly
-
Voltage:
-
22v/380v/440v customered
-
Power (kW):
-
11 kW
-
Product name:
-
FSY11
-
Name:
-
HIGH-SHEARING EMULSIFIER
-
Advantage:
-
Easy Operation High Efficiency
-
Certification:
-
CE ISO
-
Function:
-
Emulsifier Homogenizer
General:
A farfly in batch high shear mixer offers a full range of mier for production scale. The design exceeds the high quality standards necessary to achieve optimal process results and withstand the rigors of difficult processes that require high shear mixing.The high shear mixer doesn't simply mix. It emulsifies, homogenises, solubilises, suspends, disperses and disintegrates solids. Each mixer, with its precision-engineered rotor/stator workhead, far outperforms conventional mixers,improving quality, product consistency and process efficiency.
Principle:
The high shear emulsifier is capable of disribuing more than one phase into another continuous phase efficiently, evenly, swifty, whereas, usually they are insoluble to each. Due to the strong momentum caused by he very high line-speed and the high-frequency mechanical effects of the rotor, the materials subjected to the strong mechanical and hydraulic shear, centrifugal squeeze, liquid friction, impact, tear, and comprehensive force, the mutually insoluble liquid, solid and gas phases are evenly, finely dispersed and emulified immediately. By repeating this continuously, we get stable high-quality products.
Characeristics:
Using electric hydraulic lifting
Simple, fast and flexible movements
Match with pulling cylinders and their fixtures
Suits for medium and large sized production
Features of FSA high-shearing emulsifier :
Capacity
100 - 20,000 litres.
Workheads
Interchangeable workheads available for all models.
Materials of Construction
Product contact in SS304 or 316L stainless steel.
Motor Specification
1-132 kW, TEFC, flame proof, ATEX approved and stainless steel motors available as standard.
Mounting
All mixers can be supplied with either a rectangular or circular flange for mounting on the vessel. Smaller models can be mounted
on specially constructed mobile hydraulic floor stands.
Sealing
Where sealing is required, lip seals and single or double mechanical shaft seals can be supplied.
Cleaning
Simple, easy-to-clean construction.
100 - 20,000 litres.
Workheads
Interchangeable workheads available for all models.
Materials of Construction
Product contact in SS304 or 316L stainless steel.
Motor Specification
1-132 kW, TEFC, flame proof, ATEX approved and stainless steel motors available as standard.
Mounting
All mixers can be supplied with either a rectangular or circular flange for mounting on the vessel. Smaller models can be mounted
on specially constructed mobile hydraulic floor stands.
Sealing
Where sealing is required, lip seals and single or double mechanical shaft seals can be supplied.
Cleaning
Simple, easy-to-clean construction.
Types of High shearing emulsifier :
|
Type
|
Power
KW |
Handling Capacity
L |
Speed
RPM |
L
(mm) |
W
(mm) |
H
(mm) |
|
FSY 11
|
11
|
600
|
2900
|
1600
|
900
|
2000
|
|
FSY 22
|
22
|
1000
|
1440
|
2100
|
1100
|
2400
|
|
FSY 37
|
37
|
2000
|
1440
|
2300
|
1100
|
2600
|
|
FSY 55
|
55
|
3000
|
980
|
2700
|
1400
|
2800
|
