- Product Details
- {{item.text}}
Quick Details
-
Dimension:
-
2235*1180*1390mm
-
Place of Origin:
-
Shanxi, China
-
Vehicle size (length * width * height):
-
2235*1180*1390mm
-
Seat height:
-
530mm
-
Minimum ground clearance:
-
270mm
-
Minimum turning diameter:
-
7.4m
-
Curb weight:
-
395kg
-
Maximum load bearing mass:
-
230kg
-
Fuel supply:
-
EFI
-
Ignition method:
-
ECU
-
Fuel tank capacity:
-
18L
Quick Details
-
Displacement:
-
400cc
-
Brand Name:
-
CF
-
Tire Size:
-
Front: AT 25*8-12/Rear: AT 25*10-12
-
Dimension:
-
2235*1180*1390mm
-
Place of Origin:
-
Shanxi, China
-
Vehicle size (length * width * height):
-
2235*1180*1390mm
-
Seat height:
-
530mm
-
Minimum ground clearance:
-
270mm
-
Minimum turning diameter:
-
7.4m
-
Curb weight:
-
395kg
-
Maximum load bearing mass:
-
230kg
-
Fuel supply:
-
EFI
-
Ignition method:
-
ECU
-
Fuel tank capacity:
-
18L
Marketing Campaign
Marketing Campaign
Product Images
Product Images
Product Paramenters
Product Paramenters
|
Vehicle size (length * width * height)
|
2235*1180*1390mm
|
|
Wheelbase
|
1480mm
|
|
Seat height
|
530mm
|
|
Minimum ground clearance
|
270mm
|
|
Minimum turning diameter
|
7.4m
|
|
Vehicle curb weight
|
395kg
|
|
Maximum load bearing mass
|
230kg
|
|
Fuel tank capacity
|
18L
|
|
Engine type
|
Single-cylinder, water-cooled,
four-stroke, SOHC, four-valve
|
|
Displacement
|
580cc
|
|
Bore*stroke
|
91*89.2mm
|
|
Maximum power/
corresponding rotational speed
|
30kW/6750rpm
|
|
Maximum torque/
corresponding rotational speed
|
49N·m/5250rpm
|
|
Compression ratio
|
10.68:1
|
|
Fuel supply
|
EFI
|
|
Ignition method
|
ECU
|
|
Transmission type
|
CVT
|
|
Drive mode
|
Two-wheel drive / four-wheel drive
electronic control conversion
|
|
Braking method
|
Four-wheel brake (CBS) + rear wheel parking
|
|
Suspension method
|
Front/rear: Double rocker arm independent suspension
|
|
Shock absorber type
|
Front/Rear: Coil spring + oil damping
|
|
Wheel hub specifications
|
Front: 12*6.0 AT
Rear: 12*7.5 AT
|
|
Tire specifications
|
Front: AT 25*8-12
Rear: AT 25*10-12
|
|
Optional color
|
Lava Orange, Pearl Injected Blue,
Titanium Grey, Truetimber Camo
|
