Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-SCI02-PA-5000
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
100*300*440
-
Weight:
-
10kgs
-
Certificate:
-
CE, ROHS
-
Product name:
-
High efficiency rechargeable power inverter with battery
-
Power:
-
5000w
-
Output waveform:
-
Pure Sine Wave Output
-
Efficiency:
-
98%
-
Display:
-
LCD Display
-
Control Method:
-
MPPT
-
Communication interface:
-
WiFi
-
Input Voltage:
-
230 VAC
-
Maximum Charging Current:
-
80A
-
Frequency Range:
-
50 Hz/60 Hz
Quick Details
-
Output Current:
-
20A
-
Network:
-
WIFI
-
Customized support:
-
NO
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Anern
-
Model Number:
-
AN-SCI02-PA-5000
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
100*300*440
-
Weight:
-
10kgs
-
Certificate:
-
CE, ROHS
-
Product name:
-
High efficiency rechargeable power inverter with battery
-
Power:
-
5000w
-
Output waveform:
-
Pure Sine Wave Output
-
Efficiency:
-
98%
-
Display:
-
LCD Display
-
Control Method:
-
MPPT
-
Communication interface:
-
WiFi
-
Input Voltage:
-
230 VAC
-
Maximum Charging Current:
-
80A
-
Frequency Range:
-
50 Hz/60 Hz
Most Popular Products
Product Description
This is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Specification
Features：
1. Pure sine wave inverter
2. Inverter running without battery
3. Built-in MPPT solar controller
4. Configurable input voltage range for home appliances and personal computers via LCD setting
5. Configurable battery charging current based on applications via LCD setting 6. Configurable AC/Solar Charger priority via LCD
setting
7. Compatible to mains voltage or generator power
8. Auto restart while AC is recovering
9. Overload/ Over temperature/ short circuit protection
10. Smart battery charger design for optimized battery performance
11. Cold start function
1. Pure sine wave inverter
2. Inverter running without battery
3. Built-in MPPT solar controller
4. Configurable input voltage range for home appliances and personal computers via LCD setting
5. Configurable battery charging current based on applications via LCD setting 6. Configurable AC/Solar Charger priority via LCD
setting
7. Compatible to mains voltage or generator power
8. Auto restart while AC is recovering
9. Overload/ Over temperature/ short circuit protection
10. Smart battery charger design for optimized battery performance
11. Cold start function
|
Model
|
SCI02-PA-5000
|
|
|
RATED POWER
|
5000W
|
|
|
INPUT
|
|
|
|
Voltage
|
230 VAC
|
|
|
Selectable Voltage Range
|
170-280 VAC (For Personal Computers)
|
|
|
|
90-280 VAC (For Home Appliances)
|
|
|
Frequency Range
|
50 Hz/60 Hz (Auto sensing)
|
|
|
OUTPUT
|
|
|
|
AC Voltage Regulation (Batt. Mode)
|
230VAC ± 5%
|
|
|
Transfer Time
|
10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
|
|
|
Waveform
|
Pure sine wave
|
|
|
BATTERY & AC CHARGER
|
|
|
|
Battery Voltage
|
48 VDC
|
|
|
Floating Charge Voltage
|
54 VDC
|
|
|
Overcharge Protection
|
63 VDC
|
|
|
SOLAR CHARGER
|
|
|
|
Maximum PV Array Power
|
5000 W
|
|
|
MPPT Range @ Operating Voltage
|
120 ~ 450 VDC
|
|
|
Maximum PV Array Open Circuit Voltage
|
500 VDC
|
|
|
Maximum Charging Current
|
80A
|
|
|
Maximum Efficiency
|
98%
|
|
|
PHYSICAL
|
|
|
|
Dimension, D x W x H (mm)
|
448*295*105
|
|
|
Net Weight (kgs)
|
9.9
|
|
|
Communication interface
|
WIFI
|
|
|
OPERATING ENVIRONMENT
|
|
|
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|
|
Operating Temperature
|
0°C - 55°C
|
|
|
Storage Temperature
|
–15°C - 60°C
|
|
