Quick Details
-
Memory Type:
-
DDR3
-
Graphics Card Type:
-
Integrated-need CPU support
-
Chipset:
-
Intel Celeron J1900
-
Place of Origin:
-
Guangdong, China
-
CPU:
-
Onboard Intel Celeron J1900 Processor
-
Audio function:
-
HD Audio Audio input and output are supported
-
RAM:
-
1 x DDR3 204PIN SO-DIMM slot
-
Storage function:
-
1x SATA interface1 x M-SATA SSD port
-
Expansion bus:
-
1X MINI PCI-E
-
USB:
-
2*USB3.0 4*USB2.0
-
Power supply mode:
-
DC_IN 12
-
dimension:
-
121.6mm * 121.6mm
-
Operating temperature:
-
-20-55 ° C
-
Ambient temperature:
-
5~90 ° C
Quick Details
-
Maximum Ram Capacity:
-
8GB
-
Application:
-
Desktop
-
Form Factor:
-
ATX
-
Memory Type:
-
DDR3
-
Graphics Card Type:
-
Integrated-need CPU support
-
Chipset:
-
Intel Celeron J1900
-
Place of Origin:
-
Guangdong, China
-
CPU:
-
Onboard Intel Celeron J1900 Processor
-
Audio function:
-
HD Audio Audio input and output are supported
-
RAM:
-
1 x DDR3 204PIN SO-DIMM slot
-
Storage function:
-
1x SATA interface1 x M-SATA SSD port
-
Expansion bus:
-
1X MINI PCI-E
-
USB:
-
2*USB3.0 4*USB2.0
-
Power supply mode:
-
DC_IN 12
-
dimension:
-
121.6mm * 121.6mm
-
Operating temperature:
-
-20-55 ° C
-
Ambient temperature:
-
5~90 ° C
|
CPU
|
Onboard Intel® Celeron J1900 Processor, FCBGA1170 quad core, four threads, 2.00 GHzMain frequency, 2 MB L2 cache, TDP 10W
processor |
|
|
|
|||
|
Audio function
|
Onboard Realtek HD Codec audio supports 5.1 channelsHD Audio
supports audio input and output |
|
|
|
|||
|
Memory
|
1x DDR3 204PIN SO-DIMM slot (memory support 1.35V)
Support DDR3L-1333 The maximum memory is 8GB |
|
|
|
|||
|
Storage functions
|
1 x SATA ports
1 x M-SATA SSD interface |
|
|
|
|||
|
Expansion bus
|
1×MINI PCI-E
|
|
|
|
|||
|
The back plane is 1/0
|
1x DCJACK power port 1 x HDMI port 2x Dual layer USB2.0 port
1 x dual-layer USB3.0 ports(Upper port supports USB2.0 only) 2 x COM interface (com1 onlyAdjustable 485） 2 x LAN interface 1 x VGA port 1 x audio port 1 x switch button |
|
|
|
|||
|
Onboard 1/O
|
1x7 pin SATA 1 x SATA power supply port
1 x front panel ports(F_PANEL) 1 x CPU fan power socket 1 x SIMB card slot |
|
|
|
|||
|
Power source
|
Power supply type DC 12V input, 5.5*2.5DC connector
Power consumption Typical power consumption: 10W, supports power-on |
|
|
|
|||
|
Working environment
|
Operating temperature -20°C ~ 60°℃
Working humidity 0% ···· 90% relative humidity, no condensation |
|
|
|
|||
|
dimension
|
121.6x 121.6mm
|
|
|
|
|||
Question: Are you a manufacturer?
Answer: Yes, we have more than 10 years of R&D and manufacturing experience.
Question: What is the Minimum Order Quantity (MOQ)?
Answer: We can sell one piece sample for your test.
Question: What is the Minimum Order Quantity (MOQ)?
Answer: We can sell one piece sample for your test.
Question: What payment method do you accept?
Answer: T/T, Western Union, PayPal,Alibaba(Visa/Mastercard).
Question: What is the lead time of your products?
Answer: 1-3 days for one sample, 25 working days for a large quantity.
Question: Can you put my brand name (logo) on these products?
Answer: Yes, We can support OEM/ODM service, the process of customization is following:
1: Provide your specific requirement.
2: Our design engineers draw the design draft.
3: you confirm the design draft.
4. We start produce it.
Answer: Yes, we have more than 10 years of R&D and manufacturing experience.
Question: What is the Minimum Order Quantity (MOQ)?
Answer: We can sell one piece sample for your test.
Question: What is the Minimum Order Quantity (MOQ)?
Answer: We can sell one piece sample for your test.
Question: What payment method do you accept?
Answer: T/T, Western Union, PayPal,Alibaba(Visa/Mastercard).
Question: What is the lead time of your products?
Answer: 1-3 days for one sample, 25 working days for a large quantity.
Question: Can you put my brand name (logo) on these products?
Answer: Yes, We can support OEM/ODM service, the process of customization is following:
1: Provide your specific requirement.
2: Our design engineers draw the design draft.
3: you confirm the design draft.
4. We start produce it.
