Quick Details
-
Dimension(L*W*H):
-
1100*1100*2750
-
Weight:
-
750 kg
-
treatment of air flow:
-
4500m3/h
-
motor power:
-
5.5kw
-
voltage:
-
3x380v/50hz
-
clearing method:
-
automatic cleaning
-
compressed air:
-
0.5-0.6MPa
-
filtering area:
-
60m2
-
filtration efficiency:
-
>99.9%
-
numbers of cylinder:
-
4 pcs filter cartridge
-
dimensions (mm):
-
1100*1100*2750
-
noise:
-
<72dB(A)
Quick Details
-
Minimum Particle Size:
-
0.3um
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
KAISEN
-
Dimension(L*W*H):
-
1100*1100*2750
-
Weight:
-
750 kg
-
treatment of air flow:
-
4500m3/h
-
motor power:
-
5.5kw
-
voltage:
-
3x380v/50hz
-
clearing method:
-
automatic cleaning
-
compressed air:
-
0.5-0.6MPa
-
filtering area:
-
60m2
-
filtration efficiency:
-
>99.9%
-
numbers of cylinder:
-
4 pcs filter cartridge
-
dimensions (mm):
-
1100*1100*2750
-
noise:
-
<72dB(A)
Features
Central Control system implements real-time monitoring and analysis on a number of important parameter of equipments in the operation and show them in the display, and it has self-diagnosis function, showing abnormal and error conditions in the operation of the equipment automatically. The central dust & fume purification system' s performance is controlled by PLC controlling system .
The functionality of a filter lies in the filter element's material, Kaisen's filter element is specially developed for the purification of fume and fine particles generated in welding and cutting, solved this industry's problem of low filtration precision and filter element's blocking. And the outer surface of the cartridge is covered by a layer of PTFE film layer through heat treatment a special process. Cartridge wall is thin in structure and has high strength, and the surface film layer has a very uniform pores, making a network structure with a bore diameter of 0.3 microns below.
Rotary dust blowing device is inserted inside the filter cartridge, and very close to the cartridge's inner wall. When the solenoid valve opens, compressed air enter into two pipes drilled with nozzles, implementing rotary blowing to clean every part of the filter cartridge. Compared with externally placed blowing nozzles, rotary dust blowing "nozzles" blow force is even on every part of the cartridge, and have a thorough cleaning, avoid big noise and damage to the cartridge caused by instant huge blow impact of the externally placed blowing method.
To the position polluted by a little oil mist, the company's special spray device not only dilutes oil mist and prevents the dust from attaching to the filter surface to reduce its service life, but also plays a role in fire prevention.
Technology Data
|
Model |
KSDC-8604A/A1 |
KSDC-8604B/B1 |
KSDC-8606B/B1 |
KSDC-8609B2 |
|
Fan Air Flow |
6500/8200±300 m3/h |
6000/8000±300 m3/h |
8000/12000±500 m3/h |
15500±500 m3/h |
|
Inlet Air Flow |
4500/6800m3/h |
5000/6500m3/h |
6500/9500m3/h |
13500m3/h |
|
Motor Power |
5.5/7.5kW |
5.5/7.5KW |
7.5/11KW |
15kW |
|
Power Supply |
3x380V/50Hz |
3x380V/50Hz |
3x380V/50Hz |
3x380V/50Hz |
|
Filter Material |
Polyester + PTFE |
Polyester + PTFE |
Polyester + PTFE |
Polyester + PTFE |
|
Filtration Area |
60m2 |
60 m2 |
90 m2 |
135 m2 |
|
Filtration Efficiency |
≥99.9% |
≥99.9% |
≥99.9% |
≥99.9% |
|
Filtration Precision |
≥0.3um |
≥0.3um |
≥0.3um |
≥0.3um |
|
Filter Cartridge |
4 Pcs |
4 Pcs |
6 Pcs |
9 Pcs |
|
Cleaning Method |
Automatic cleaning |
Automatic cleaning |
Automatic cleaning |
Automatic cleaning |
|
Compressed Air |
0.5~0.6Mpa |
0.5~0.6Mpa |
0.5~0.6Mpa |
0.5~0.6Mpa |
|
Noise Level |
≤72±5 dB |
≤72±5 dB |
≤75±5 dB |
≤75±5 dB |
|
Dimension (WxDxH) |
1100×1100×2750mm |
1170×1663×2150mm |
1620×1750×2150mm |
1900×2150×2400mm |
|
Weight |
750±20kg |
770±20kg |
1050/1120±20kg |
1875±20kg |
